01 |
7082K00012
|
Main pump |
1 |
InternBDB: HPV 375+375 (708-2K-00012 DFL 500~) 796 435 73 | InternKon: 946 054 40 / 2
|
|
|
|
02 |
7082K00022
|
Main pump assy. fig-nos. 01,10-16 |
1 |
InternBDB: HPV 375 + 375 + HPF 125 (708-2K-00022 DFM 500~) 796 436 73 | InternKon: 946 054 40 / 3
|
|
|
|
03 |
7082K00032
|
Main pump assy. fig-nos. 01,12,13,20,21,24-29 |
1 |
InternBDB: HPV 375 + 375 + SAL 63 (708-2K-00032 DFN 500~) 796 437 73 | InternKon: 946 054 40 / 4
|
|
|
|
04 |
7051236140
|
Pump |
1 |
InternBDB: SAR (3) 63 (7051236140) 797 117 73 | InternKon: 946 054 40 / 5
|
|
|
|
05 |
307 888 99
|
Bolt |
18 |
InternBDB: M 24x65 8.8 DIN 00933 | InternKon: 946 054 40 / 12
|
|
|
|
06 |
340 471 99
|
Washer |
18 |
InternBDB: B 25,0 | InternKon: 946 054 40 / 13
|
|
|
|
07 |
307 587 99
|
Bolt |
4 |
InternBDB: M 12x30 / DIN 933 | InternKon: 946 054 40 / 14
|
|
|
|
08 |
340 652 99
|
Washer |
4 |
InternBDB: B 13,0 DIN 125 | InternKon: 946 054 40 / 15
|
|
|
|
09 |
518 280 98
|
O-Ring |
3 |
InternBDB: 170x3 70 Sh / DIN 3770 | InternKon: 898 152 40 / 280
|
|
|
|
10 |
708 1G 00020
|
Fan pump |
1 |
InternBDB: HPF 125 (708-1G-00020) 793 406 73
|
|
|
|
11 |
708 2K 19160
|
Coupling |
1 |
InternBDB: 708-2K-19160 793 977 73
|
|
|
|
12 |
708 2K 19140
|
Seal |
2 |
InternBDB: 708-2K-19140 793 978 73
|
|
|
|
13 |
04065 06220
|
Snap ring |
2 |
InternBDB: 04065-06220 793 979 73
|
|
|
|
14 |
07000 A 5165
|
O-Ring |
2 |
InternBDB: 07000-A-5165 793 980 73
|
|
|
|
15 |
01643331445
|
Washer |
4 |
InternBDB: 01643 33 1445 795 137 73
|
|
|
|
16 |
01010 61445
|
Bolt |
4 |
InternBDB: 01010 61445 793 981 73
|
|
|
|
17 |
518 279 98
|
O-Ring |
1 |
InternBDB: 125x3 70Sh / DIN 3770 | InternKon: 898 152 40 / 270
|
|
|
|
18 |
7082K12230
|
Shaft seal |
3 |
InternBDB: 708-2K-12230 796 004 73
|
|
|
|
19 |
8870132126
|
Spacer |
3 |
InternBDB: 887-0132-126 796 005 73
|
|
|
|
20 |
705 21 36240
|
Gear pump |
1 |
InternBDB: 705-21-36240 793 407 73
|
|
|
|
21 |
708 2K 19180
|
Coupling |
1 |
InternBDB: 708-2K-19180 793 983 73
|
|
|
|
22 |
0406501204
|
Snap ring |
3 |
InternBDB: 04065-01204 796 006 73
|
|
|
|
24 |
708 2K 19170
|
Plate |
1 |
InternBDB: 708-2K-19170 793 984 73
|
|
|
|
25 |
07000 A2100
|
O-Ring |
1 |
InternBDB: 07000-A-2100 793 985 73
|
|
|
|
26 |
01010 61455
|
Bolt |
4 |
InternBDB: M14x2x55 (01010-61455) 793 986 73
|
|
|
|
28 |
07372 21235
|
Bolt |
2 |
InternBDB: M12x1,75x35 (07372-21235) 793 988 73
|
|
|
|
29 |
01643 31232
|
Washer |
2 |
InternBDB: 01643 312 32 795 138 73
|
|
|
|
31 |
7022107640
|
Solenoid valve |
1 |
InternBDB: 702-21-07640 797 483 73
|
|
|
|
32 |
7082K16320
|
O-Ring |
1 |
InternBDB: 708-2K-16320 797 484 73
|
|
|
|
33 |
7082K16310
|
O-Ring |
2 |
InternBDB: 708-2K-16310 797 485 73
|
|
