PC3000-6E S/N 06262

01 02 02 03 04 05 05 06 07 09 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 27 28 28 29 30 31 32 32 33 33 34 35 36 37 38 39 40 41 41 42 42 43 51 52 53 54 55 56 57 57

#	Part Number	Partname	Quantity	Options
01	907 952 40	Camera	1	InternBDB: Mekra 70 DEG 28 5611 070 \| InternKon: 939 314 40 / 1
02	907 954 40	Monitor	1	InternBDB: Mekra 08 5611 200 \| InternKon: 939 314 40 / 2
03	907 955 40	Frame	1	InternBDB: Mekra 20 5610 200 \| InternKon: 939 314 40 / 3
04	907 957 40	Adapter cable	1	InternBDB: Mekra 09 5610 350 \| InternKon: 939 314 40 / 4
05	948 866 40	Harness camerasystem	1	InternKon: 939 314 40 / 5
06	907 969 40	Cable 11 m	1	InternBDB: Mekra 11M 09 5610 121 \| InternKon: 939 314 40 / 6
07	907 970 40	Cable 5 m	1	InternBDB: Mekra 5M 09 5610 111 \| InternKon: 939 314 40 / 7
09	907 986 40	Retainer	1	InternBDB: STEEL BRACKET (MCM-0068) 20 5610 100 \| InternKon: 939 314 40 / 9
12	948 823 40	Base plate	1	InternBDB: A-105 ST37-2 10X146X153 \| InternKon: 939 314 40 / 12
13	255 034 40	Housing, empty	1	InternBDB: ALUGEHAEUSE A 105 \| InternKon: 939 314 40 / 13
14	318 053 99	Bolt	2	InternBDB: M 4X20 4.8 DIN 00084 \| InternKon: 939 314 40 / 14
15	941 472 40	Plug	2	InternBDB: M32x1,5 23254UPMK 1/7 * \| InternKon: 939 314 40 / 15
16	0443452711	Clip NW 27	5	InternBDB: 77 KES 04434 \| InternKon: 939 314 40 / 16
17	0443552511	Clip NW 25,5	4	InternBDB: 77 KES 04435 \| InternKon: 939 314 40 / 17
18	517 122 98	Lock washer	4	InternBDB: 10 STZN WN 65593840 \| InternKon: 939 314 40 / 18
19	307 775 99	Bolt	4	InternBDB: M10 X 20 8.8 DIN 00933 \| InternKon: 939 314 40 / 19
20	340 465 99	Washer	2	InternBDB: B 10,5 140HV DIN 00125 \| InternKon: 939 314 40 / 20
21	507 037 98	Nut	2	InternBDB: M10 8 DIN 00985 \| InternKon: 939 314 40 / 21
22	931 337 40	Cover	1	InternBDB: KAMERA RST37-2 5X142X390 \| InternKon: 948 836 40 / 1
23	307 754 99	Bolt	4	InternBDB: M 8 X 25 8.8 DIN 00933 \| InternKon: 948 836 40 / 2
24	340 507 99	Washer	4	InternBDB: A 8,4 140HV DIN 00125 \| InternKon: 948 836 40 / 3
25	334 599 99	Nut	4	InternBDB: M 8 8 DIN 00985 \| InternKon: 948 836 40 / 4
26	942 075 40	Monitor Retrainer	1	InternKon: 942 073 40 / 1
27	500 679 98	Bolt	6	InternBDB: M 6 X 15 10.9 DIN 00933 \| InternKon: 942 073 40 / 2
28	517 120 98	Lock washer	6	InternBDB: 6 STZN WN 65593840 \| InternKon: 942 073 40 / 3
29	942 784 40	Monitor Retainer	1	InternKon: 942 073 40 / 4
30	942 782 40	Monitor Retainer	1	InternKon: 942 073 40 / 5
31	942 757 40	Monitor Retainer	1	InternKon: 942 073 40 / 6
32	506 307 98	Clamp Set	2	InternBDB: L-5-G-38 PP DIN 03015 \| InternKon: 942 073 40 / 7
33	341 419 99	Screw	4	InternBDB: M 6X 70 8.8 DIN 00912 \| InternKon: 942 073 40 / 8
34	942 789 40	Adapter plate	1	InternBDB: 5X166X258 \| InternKon: 942 073 40 / 9
35	320 005 99	Screw	4	InternBDB: M 4X 16 8.8 DIN 00912 \| InternKon: 942 073 40 / 10
36	334 649 99	Nut	4	InternBDB: M 4 6 A2E DIN 00985 \| InternKon: 942 073 40 / 11
37	340 459 99	Washer	4	InternBDB: A 4,3 140HV DIN 00125 \| InternKon: 942 073 40 / 12
38	931 377 40	Plate	1	InternBDB: 5X95X251 \| InternKon: 942 073 40 / 13
39	942 785 40	Monitor Retrainer	1	InternKon: 942 073 40 / 14
40	319 131 99	Screw	4	InternBDB: M 6X 20 8.8 DIN 00912 \| InternKon: 942 073 40 / 15
41	534 020 99	Weld on plate	2	InternBDB: L-AP-K-5 W1 DIN 03015 \| InternKon: 942 073 40 / 16
42	511 858 98	Cover plate	2	InternBDB: L-5 W1 DIN 03015 \| InternKon: 942 073 40 / 17
43	507 025 98	Nut	4	InternBDB: M 6 8 DIN 00985 \| InternKon: 942 073 40 / 18
51	655 652 40	Cable protection hose DN 23	-2	InternBDB: NW 23 VCSG-23B \| InternKon: 948 866 40 / 1
52	907 969 40	Cable 11 m	-2	InternBDB: MULTI CABLE 11M 09 5610 121 \| InternKon: 948 866 40 / 2
53	896 558 40	Pipe adapter DN 29/23	1	InternBDB: NW 29/23 BAVR-29G23G \| InternKon: 948 866 40 / 3
54	907 980 40	Fitting DN 23	1	InternBDB: NW 23 BVIVG-U353 \| InternKon: 948 866 40 / 4
55	941 472 40	Plug	1	InternBDB: M32x1,5 23254UPMK 1/7 * \| InternKon: 948 866 40 / 5
56	907 690 40	Cable union DN 23	1	InternBDB: NW 23 GERADE BVNV-M253 \| InternKon: 948 866 40 / 6
57	932 557 40	Heat Protection hose	-2	InternBDB: 91F2863 - BLAU - \| InternKon: 948 866 40 / 7
\|$$48		Bulk ware, state length required	-2

Komatsu PC3000-6E S/N 06262 parts catalog PDF

CAMERASYSTEM (255-1960a) in PC3000-6E S/N 06262. Diagram image and parts list.
