Diagram image 1 of 2

PC3000-6E S/N 06262

01 01 02 03 05 11 11 12 13 14 15 19 20 21 22 23 24 25 26 26 26 26 27 28 29 38 39 40 41 42 43 44 45 46 81 82 82 82 83 83 83

PC3000-6E S/N 06262

04 06 07 08 09 10 12 12 30 30 31 32 33 33 34 34 34 34 34 34 35 35 35 35 35 35 36 36 36 36 37 37 37 47 48 48 48 48 48 48 49 49 49 49 49 50 50 51 52 53 54 54 54 54 55 55 55 55 56 56 57 57 57 58 58 58 59 60 60 61

#	Part Number	Partname	Quantity	Options
01	948 837 40	Rubber plate	1	InternBDB: 3X656X671 \| InternKon: 948 838 40 / 1
02	0443453211	Clip NW 32	4	InternBDB: KES 04434 \| InternKon: 948 838 40 / 2
03	0443452110	Clip NW 21,5	4	InternBDB: 77 KES 04434 \| InternKon: 948 838 40 / 3
04	948 844 40	Harness 7S1.1-7G2	1	InternKon: 948 838 40 / 4
05	948 846 40	Harness Batterie-Heater	1	InternKon: 948 838 40 / 5
06	948 843 40	Harness S2.1-G2	1	InternKon: 948 838 40 / 6
07	948 841 40	Harness control voltage	1	InternKon: 948 838 40 / 7
08	948 839 40	Harness G1- G2+	1	InternKon: 948 838 40 / 8
09	948 840 40	Cable Batterie 7G1- 7G2+	1	InternKon: 948 838 40 / 9
10	948 845 40	Harness Supply emergency light	1	InternKon: 948 838 40 / 10
11	159 984 40	Battery switch	2	InternBDB: 6EK 008 458-011 \| InternKon: 948 838 40 / 11
12	507 025 98	Nut	4	InternBDB: M 6 8 DIN 00985 \| InternKon: 948 838 40 / 12
13	321 014 99	Screw	4	InternBDB: M 6X16 4.8 B2E DIN 00084 \| InternKon: 948 838 40 / 13
14	502 618 98	Half clamp	10	InternBDB: S-3-E PP DIN 03015 \| InternKon: 948 838 40 / 14
15	510 452 98	Grommet	10	InternBDB: S-3-20 GUMMI DIN 03015 \| InternKon: 948 838 40 / 15
19	430 152 40	Thread rod 270 lg	1	InternBDB: M10X 270 \| InternKon: 948 838 40 / 19
20	933 371 40	Thread rod 200 lg	1	InternBDB: M10X 200 \| InternKon: 948 838 40 / 20
21	933 370 40	Thread rod 150 lg	1	InternBDB: M10X 150 \| InternKon: 948 838 40 / 21
22	319 459 40	Thread rod 85 lg	1	InternBDB: M10X 85 \| InternKon: 948 838 40 / 22
23	534 004 99	Cover plate	4	InternBDB: S-DP-A-3 W1 DIN 03015 \| InternKon: 948 838 40 / 23
24	517 122 98	Lock washer	4	InternBDB: 10 STZN WN 65593840 \| InternKon: 948 838 40 / 24
25	507 037 98	Nut	4	InternBDB: M10 8 DIN 00985 \| InternKon: 948 838 40 / 25
26	309 691 40	Battery	4	InternBDB: 12V 200AH ETN 725 103 115 GEF+GEL DINEN 60095 \| InternKon: 948 838 40 / 26
27	887 009 40	Angle	2	InternKon: 948 838 40 / 27
28	332 353 99	Nut	4	InternBDB: M 12 10 DIN 00934 \| InternKon: 948 838 40 / 28
29	340 652 99	Washer	4	InternBDB: B 13,0 140HV A2E DIN 00125 \| InternKon: 948 838 40 / 29
30	654 422 40	Cable lug 25/10	1	InternBDB: 25MM2/M10 BOLZEN = M10 104 R/10 \| InternKon: 948 844 40 / 1
31	256 514 40	Plate	15	InternBDB: 15X30X1,5 ALU \| InternKon: 948 844 40 / 2
32	056 292 40	Cable strap	15	InternBDB: TY 23 M \| InternKon: 948 844 40 / 3
33	654 423 40	Cable lug 25/12	1	InternBDB: 25MM2/M12 BOLZEN = M12 104 R/12 \| InternKon: 948 844 40 / 4
34	932 556 40	Heat Protection hose	-2	InternBDB: 91F2861 - ROT - \| InternKon: 948 844 40 / 5
35	932 557 40	Heat Protection hose	-2	InternBDB: 91F2863 - BLAU - \| InternKon: 948 844 40 / 6
36	655 651 40	Cable protection hose DN 17	-2	InternBDB: NW 17 VCSG-17B \| InternKon: 948 844 40 / 7
37	906 023 40	Cable 25,0 bl	-2	InternBDB: 25,0MM2 BLAU 092500BL \| InternKon: 948 844 40 / 8
38	635 042 40	Wire end ferrule 1,5	3	InternBDB: D=1,5 203124-20 CE015 U \| InternKon: 948 846 40 / 1
39	655 650 40	Cable protection hose DN 12	-2	InternBDB: NW 12 VCST-12B \| InternKon: 948 846 40 / 2
40	796 426 73	Plug	1	InternBDB: KES 08192 0819213820 \| InternKon: 948 846 40 / 3
41	907 692 40	Fitting PG 9	1	InternBDB: M16/NW12 BVIR-M162 \| InternKon: 948 846 40 / 4
42	907 703 40	Cable union	2	InternBDB: 21650YNPM4X3 \| InternKon: 948 846 40 / 5
43	896 520 40	End pin	1	InternBDB: BO 3,0X25 \| InternKon: 948 846 40 / 6
44	907 890 40	Cable 1,5black	-2	InternBDB: 1,5MM2 SCHWARZ 090150SW \| InternKon: 948 846 40 / 9
45	655 873 40	Cable 1,5 bl	-2	InternBDB: 1,5MM2 BLAU 090150BL \| InternKon: 948 846 40 / 10
46	655 079 40	Cable 1.5 gr/ye	-2	InternBDB: 1,5MM2 GRUEN/GELB 090150GG \| InternKon: 948 846 40 / 11
47	654 420 40	Cable lug	1	InternBDB: 35MM2/M10 BOLZEN = M10 105 R/10 \| InternKon: 948 843 40 / 1
48	654 421 40	Cable lug 35	1	InternBDB: 35MM2/M12 BOLZEN = M12 105 R/12 \| InternKon: 948 843 40 / 4
49	655 689 40	Cable 35 qmm	-2	InternBDB: 35,0MM2 SCHWARZ 093500SW \| InternKon: 948 843 40 / 8
50	056 076 40	Protection cap	2	InternBDB: 2000 558000 \| InternKon: 948 841 40 / 1
51	654 420 40	Cable lug	3	InternBDB: 35MM2/M10 BOLZEN = M10 105 R/10 \| InternKon: 948 841 40 / 2
52	906 079 40	T-Distributor DN 29	1	InternBDB: NW 29 BFTL-292929GGG \| InternKon: 948 841 40 / 4
53	655 635 40	Pipe adapter DN 29/17	1	InternBDB: NW 29/17 BAVR-29G17G \| InternKon: 948 841 40 / 5
54	906 942 40	Pole end plate, red	1	InternBDB: 457N3V02 ROT 06-84-57302/T \| InternKon: 948 841 40 / 7
55	906 940 40	Pole, plus	1	InternBDB: +M12 BOLZEN 06-80-60900/T \| InternKon: 948 841 40 / 8
56	655 696 40	Cable protection hose DN 29	-2	InternBDB: NW 29 VCSG-29B \| InternKon: 948 841 40 / 9
57	906 669 40	Wire end ferrule 35mm	3	InternBDB: 35,0MM2 TYP , 1757073 \| InternKon: 948 841 40 / 19
58	907 733 40	T-Distributor DN 23	1	InternBDB: NW 23 BVTR-232323 \| InternKon: 948 845 40 / 4
59	655 627 40	Distributor DN 23/17	1	InternBDB: NW 23/17 BVYR-231717GGG \| InternKon: 948 845 40 / 5
60	655 652 40	Cable protection hose DN 23	-2	InternBDB: NW 23 VCSG-23B \| InternKon: 948 845 40 / 9
61	906 670 40	Wire end ferrule 25mm	3	InternBDB: 25,0MM2 TYP , 1757071 \| InternKon: 948 845 40 / 16
81	966 673	Gear shift lever	2
82	346 500 99	Lock washer	4	InternBDB: 10/128
83	332 132 99	Nut	4	InternBDB: M12 / 936

Komatsu PC3000-6E S/N 06262 parts catalog PDF

BATTERIES WITH CABLES (255-2130d) in PC3000-6E S/N 06262. Diagram image and parts list.
