PC3000-6E S/N 06262

01 02 03 03 04 04 05 05 07 08 09 10 10 10 10 11 12 13 13 14 14 15 16 16 16 16 17 17 17 18 18 19 21 25 26 26 27 27 28 29 30 31 32 32 33 33 34 34 35 36 37 38 39 40 41 41 42 43 43 44 44 45 46 47 48 49 50 51 52 55 55 60

#	Part Number	Partname	Quantity	Options	Reference
01		Valve block	1	InternBDB: 886 298 40 \| InternKon: 946 630 40 / 17	485-3190c
02	635 991 40	Clamp clip	4	InternBDB: Norma 181 6011 121 \| InternKon: 946 630 40 / 18
03	634 297 40	Union	2	InternBDB: RED 25/20-PS/OMD \| InternKon: 946 630 40 / 19
04	374 419 99	Union	2	InternBDB: SDS-S25xG1 A-Type E ISO08434 \| InternKon: 946 630 40 / 20
05	004 132 98	Coupling	2	InternBDB: 20-S /341 985 40 \| InternKon: 946 630 40 / 21
07	517 121 98	Lock washer	16	InternBDB: 8 WN 655 938 40 \| InternKon: 946 630 40 / 23
08	332 334 99	Nut	4	InternBDB: M 12 /934 \| InternKon: 946 630 40 / 10
09	514 103 98	Bolt	4	InternBDB: M12x170 /933 10.9 \| InternKon: 946 630 40 / 26
10	516 180 98	Union	4	InternBDB: SWRT-S20 ISO08434-4 \| InternKon: 946 630 40 / 27
11	308 556 99	Bolt	8	InternBDB: M8x50 /931 \| InternKon: 946 630 40 / 28
12	334 599 99	Nut	8	InternBDB: 6KTMU M 8 8 DIN 00985 \| InternKon: 946 630 40 / 29
13	576 299 40	Hose assy. DN 12x1300	1	InternBDB: 240 DOL 15 DOL 15 90 \| InternKon: 946 630 40 / 30
14	517 715 98	Hose assy. DN 16x1300	1	InternBDB: 120 DOS 20 DOS 20 90 \| InternKon: 946 630 40 / 31
15	517 118 98	Lock washer	8	InternBDB: 12 WN 655 938 40 \| InternKon: 946 630 40 / 35
16	512 492 98	Hose assy. DN 16x1000	2	InternBDB: 350 DOS 20 DOS 20 \| InternKon: 946 630 40 / 46
17	517 593 98	Hose assy. DN 16x3500	2	InternBDB: 350 DOS 20 DOS 20 90 \| InternKon: 946 630 40 / 47
18	576 385 40	Hose assy. DN 12x1500	1	InternBDB: 240 DOL 15 DOL 15 90 \| InternKon: 946 630 40 / 57
19	374 413 99	Union	1	InternBDB: SDS S20X M27x2 Typ E \| InternKon: 946 630 40 / 64
21	516 165 98	Union	1	InternBDB: SWE-S20 ISO08434-4 \| InternKon: 946 630 40 / 97
25	461 133 40	Ball cock	2	InternBDB: Argus 3021-0016-5942-50 \| InternKon: 936 608 40 / 9
26	372 185 99	Union	4	InternBDB: DDS 20 / DIN 2353 \| InternKon: 936 608 40 / 31
27	370 506 99	Union	4	InternBDB: CS 20 / DIN 2353 \| InternKon: 936 608 40 / 33
28	371 977 99	Union	2	InternBDB: FFS 20 /2353 \| InternKon: 936 608 40 / 37
29	534 002 99	Weld-on plate	4	InternBDB: S-AP-A-2 / DIN 3015 \| InternKon: 936 608 40 / 38
30	534 001 99	Cover plate	4	InternBDB: S-DP-A-2 / DIN 3015 \| InternKon: 936 608 40 / 39
31	308 579 99	Bolt	8	InternBDB: M10x60 /931 \| InternKon: 936 608 40 / 40
32	517 578 98	Hose assy. DN 16x920	2	InternBDB: 350 DOS 20 DOS 20 \| InternKon: 936 608 40 / 34
33	517 579 98	Hose assy. DN 16x640	2	InternBDB: 350 DOS 20 DOS 20 90 \| InternKon: 936 608 40 / 35
34	515 812 98	Coupling	4	InternBDB: G 1/4-PC / 655 914 40 \| InternKon: 936 608 40 / 20
35	551 715 40	Hose assy. DN 16x390	2	InternBDB: 350 DOS 20 DOS 20 90 \| InternKon: 936 608 40 / 32
36	374 418 99	Socket	2	InternBDB: SDS-S20 XG 3/4 ISO 08434 \| InternKon: 936 608 40 / 30
37	502 682 98	Clamp set	8	InternBDB: S-2-G-28 / DIN 3015 \| InternKon: 936 608 40 / 41
38	372 133 99	Union	2	InternBDB: EES 20 / DIN 2353 \| InternKon: 936 608 40 / 36
39	517 121 98	Lock washer	4	InternBDB: 8 \| InternKon: 936 608 40 / 45
40	307 752 99	Bolt	4	InternBDB: M 8x20 / DIN 933 \| InternKon: 936 608 40 / 44
41	509 057 98	Clamp set	8	InternBDB: L-3-G-20 / DIN 3015 \| InternKon: 946 630 40 / 78
42	504 986 98	Screw	8	InternBDB: L-3 / DIN 3015 \| InternKon: 946 630 40 / 79
43	511 856 98	Cover plate	6	InternBDB: L-3 / DIN 3015 \| InternKon: 946 630 40 / 80
44	308 536 99	Bolt	12	InternBDB: M6x40 / DIN 931 \| InternKon: 946 630 40 / 81
45	509 058 98	Clamp set	2	InternBDB: L-3-G-23 / DIN 3015 \| InternKon: 946 630 40 / 82
46	518 060 98	Clamp set	2	InternBDB: L-5-G-36 / DIN 3015 \| InternKon: 946 630 40 / 83
47	511 858 98	Cover plate	2	InternBDB: L-5 / DIN 3015 \| InternKon: 946 630 40 / 84
48	307 740 99	Bolt	4	InternBDB: M6x60 /DIN 933 \| InternKon: 946 630 40 / 85
49	518 032 98	Clamp set	2	InternBDB: S-3-E / DIN 3015 \| InternKon: 946 630 40 / 86
50	515 628 98	Grommet	2	InternBDB: S-3-28 / DIN 3015 \| InternKon: 946 630 40 / 87
51	534 004 99	Cover plate	2	InternBDB: S-DP-A-3 / DIN 3015 \| InternKon: 946 630 40 / 88
52	308 581 99	Bolt	4	InternBDB: M10x70 / DIN 931 \| InternKon: 946 630 40 / 90
55		Accumulator	2	InternBDB: TL 551 737 40 / 551 734 40 (TT)
60		Diaphragm-type accumulator	2	InternBDB: TL 551 708 40 / 551 446 40 (TT)

Komatsu PC3000-6E S/N 06262 parts catalog PDF

TRACK ADJUSTER (255-3186) in PC3000-6E S/N 06262. Diagram image and parts list.
