HYDRAULIC CYLINDER COLD WEATHER DESIGN | PC5500-6 S/N 15081

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity
01	911 320 40	Hydraulic cylinder assy.	1
03		Cylinder	1
06	947 188 40	Thread pin	1
07	947 183 40	Groove nut	1
08	461 050 40	Piston slyding strip	2
09	440 716 40	Piston wear ring	5
10	440 718 40	O-ring	1
11	440 717 40	Seal	1
12	915 869 40	Piston assy. fig-nos. 13 and 14 (finishing after bush is installed)	1
13	456 123 40	Piston bush (Only for work shop repair)	1
14		Piston	1
15	516 883 98	O-ring	1
16	907 052 40	Support ring	2
17	502 086 98	O-ring	1
18	440 715 40	Support ring	1
19	953 843 40	Sealing flange fig-nos: 20 and 21 (finishing after bush is installed)	1
20		Bush	1
21	953 841 40	Bush (Only for work shop repair)	1
22	502 095 98	Srew Cold weather design	20
23	324 440 40	Seal kit	1
24	906 591 40	Support ring	1
25	909 367 40	Cover	1
26	501 084 98	Screw Cold weather design	24
27	906 542 40	Stripper	1
28	501 352 98	Feather key	1
29	794 783 73	Piston rod assy. fig-nos: 28,30,41,50,51	1
30		Piston rod	1
32	891 819 40	Half shim	12
33	909 364 40	Cover ring	1
40	906 730 40	Support ring for scraper fig-no. 27	1
41	907 024 40	Pin seal ring	2
42	180 477 40	Plug	1
43	922 234 40	Locking plate 2"	1
44	385 243 40	Flange seal 2"	1
49	911 371 40	Freeze in Flanged bushing	2
50	922 233 40	Freeze in bushing	1
51	004 860 98	Grease nipple	4
52	922 232 40	Connecting plate 2''	1
\|$$39	792 421 73	Seal kit for piston fig-nos. 08-11,15 and 16	-2
\|$$40	792 422 73	Seal kit for sealing flange, with slited seals, fig-nos: 17,18,23 and 27	-2
\|$$41	797 324 73	Seal kit for sealing flange, with slited seals, fig-nos: 17,18,23 and 27	-2
