BULLCLAM BUCKET 26,0 CBM (LIP WP4) | PC5500-6E S/N 15089

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity	Reference
01	931 685 40	Bullclam bucket without lip	1
02		Bullclam bucket wall	1
04	922 371 40	Plate	2
05	958 718 40	Strip	4
06	922 373 40	Strip	2
07	922 374 40	Protection rubber	2
08	511 263 98	Thread pin	20
09	507 037 98	Nut	20
12		Cylinder with piping	2	515-5035c
13	923 274 40	Pin with plate	2
14	923 271 40	Pin with plate	2
15	923 266 40	Pin	2
16	923 269 40	Pin	2
17	923 246 40	Freeze-in bushing	4
18	923 268 40	Freeze-in bushing	4
19	923 267 40	Freeze-in bushing	4
20	890 921 40	Protective frame	4
21	319 444 99	Bolt	8
22	890 884 40	Square	4
23	895 099 40	Square	4
24	890 916 40	Catch	4
25	334 600 99	Nut	8
26	923 265 40	Catch	4
27	900 749 40	Catch	4
28	923 263 40	Axle stirrup	4
29	900 750 40	Axle stirrup	4
30	923 264 40	Shackle	2
31	900 751 40	Shackle	2
32	923 241 40	Manifold	2
33	517 600 98	Hose assy. DN 32x1640	1
34	517 601 98	Hose assy. DN 32x1840	1
35	517 602 98	Hose assy. DN 32x2480	1
36	517 603 98	Hose assy. DN 32x 2280	1
37	517 192 98	Lock washer	8
38	356 209 40	Flange seal	2
39	319 288 99	Bolt	8
40	923 262 40	Ring	4
41	934 094 40	Ring	4
42	320 374 99	Bolt	4
43	307 826 99	Bolt	16
44	517 123 98	Lock washer	16
45	909 290 40	Plate	2
46	896 665 40	Plug	4
48	510 213 98	Thread pin	8
49	517 118 98	Lock washer	8
50	911 196 40	Cover	2
51	517 122 98	Lock washer	6
52	307 775 99	Bolt	6
53	356 210 40	O-ring	6
54	319 209 99	Bolt	24
55	006 638 98	Half clamp	12
56	006 639 98	Half clamp	4
60	795 610 73	Bucket clam, incl. Pos. 61, 63, 68	1
61		Bucket clam	1
62	936 399 40	Pin with plate	2
63	922 366 40	Freeze-in bushing	2
64	936 396 40	Shackle	2
65	936 397 40	Catch	4
66	307 824 99	Bolt	8
67	517 123 98	Lock washer	8
68	907 023 40	Pin seal ring	4
70	950 217 40	Castlip assy.	1
71	907 280 40	Castlip	1
72	950 193 40	Tooth adapter	6
73	941 782 40	Tooth tip	6
74	906 090 40	Wedge	6
75	941 783 40	Torque wedge pin	6
76	907 010 40	Shroud	12
77	907 281 40	Shroud	5
78	941 211 40	Toplok-boss	5
79	655 384 40	Wedge	5
80	932 748 40	Key	4
81	606 984 40	Base plate	4
82	654 381 40	Wedge	4
83	906 174 40	Runner style	2
84	906 179 40	Base style	4
85	906 183 40	Lock	4
86	906 992 40	Toplok wing shroud	2
87	660 496 40	Lock	2
88	660 497 40	Wedge	2
89	932 606 40	Thrust block	2
90	950 294 40	Wear plate	10
91	950 293 40	Base plate	6
92	906 176 40	Runner style	2
\|$$85			-2
\|$$86			-2
\|$$87			-2
\|$$88			-2
\|$$89			-2
\|$$90			-2
\|$$91			-2
\|$$92			-2
\|$$93			-2
\|$$94			-2
\|$$95			-2
\|$$96			-2
\|$$97			-2
\|$$98			-2
\|$$99			-2
\|$$100			-2
\|$$101			-2
\|$$102			-2
\|$$103			-2
\|$$104			-2
\|$$105			-2
\|$$106			-2
\|$$107			-2
\|$$108			-2
\|$$109			-2
\|$$110			-2
\|$$111			-2
\|$$112			-2
\|$$113			-2
\|$$114			-2
\|$$115			-2
\|$$116			-2
\|$$117			-2
\|$$118			-2
\|$$119			-2
\|$$120			-2
\|$$121			-2
\|$$122			-2
\|$$123			-2
\|$$124			-2
\|$$125			-2
\|$$126			-2
\|$$127			-2
\|$$128			-2
