PC3000-6 S/N 46174

Komatsu parts book diagram for PC3000-6 S/N 46174: SLEW-BRAKE VALVE

01 02 03 04 05 06 07 08 09 10 11 12 13 14

	#	Part Number	Partname	Quantity	Options	Reference
	01	655 855 40	Brake valve assy.	1	InternBDB: Rexroth MH2DBB40P9-2x/ 150-330 YP2A Nr. 938 514
	02	006 729 98	O-ring	2	InternBDB: 47,22x3,53 \| InternKon: 009 385 14 / 10
	03	319 384 99	Bolt	4	InternBDB: M20x70 /912 \| InternKon: 009 385 14 / 15
	04	805 585 73	Plate	1	InternBDB: 642 307 \| InternKon: 009 385 14 / 14
	05	793 813 73	Valve	1	InternBDB: R901078361 \| InternKon: 009 385 14 / 17
	06		Pressure sequence stage	1	InternBDB: 867 768 \| InternKon: 009 385 14 / 16	991-0184
	07	805 587 73	Plug	4	InternBDB: 642 311 \| InternKon: 009 385 14 / 6
	08	506 857 98	O-ring	4	InternBDB: 56*3 \| InternKon: 009 385 14 / 10
	09	255 012 40	Spring	4	InternBDB: 008 862 \| InternKon: 009 385 14 / 8
	10	255 011 40	Taper	4	InternBDB: 147 996 \| InternKon: 009 385 14 / 7
	11	757 411 73	Plug	2	InternBDB: 023 942 \| InternKon: 009 385 14 / 9
	12	500 582 98	O-ring	2	InternBDB: 38*3
	13	754 708	Plug	2	InternBDB: 001 729 \| InternKon: 009 385 14 / 12
	14	793 814 73	Seal kit	1	InternBDB: R961000744

Komatsu PC3000-6 S/N 46174 parts catalog PDF

SLEW-BRAKE VALVE (991-0181a) in PC3000-6 S/N 46174. Diagram image and parts list.
