PC3000-6 S/N 46174

Komatsu parts book diagram for PC3000-6 S/N 46174: SLEW RING ARR.

01 02 03 04 05 06 06 07 08 09 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

	#	Part Number	Partname	Quantity	Options	Reference
	01		Slew ring assy.	1	InternBDB: Hoesch-Rothe-Erde 191.45.27.94.000.41.1502 \| InternKon: 902 444 40 / 1	991-0262
	02	514 375 98	Bolt (standard)	96	InternBDB: M30x285 \| InternKon: 919 903 40 / 28
	02	517 878 98	Bolt (cold weather design)	96	InternBDB: 6KTSHR M30X 285 10.9 KALTZ WN 34192140 \| InternKon: 919 903 40 / 28
	03	255 057 40	Washer	96	InternBDB: 31 / 6916 \| InternKon: 919 903 40 / 29
	04	504 975 98	Bolt (standard)	88	InternBDB: M30x190 / 341 920 40 \| InternKon: 919 901 40 / 3
	04	505 781 98	Bolt (cold weather design)	88	InternBDB: 6KTSHR M30X 190 10.9 KALTZ WN 34192140 \| InternKon: 919 901 40 / 3
	05	930 631 40	Test bolt (standard)	8	InternBDB: M30x190 \| InternKon: 919 901 40 / 2
	05	928 844 40	Test bolt (cold weather design)	8	InternBDB: MESSHR M30X190 \| InternKon: 919 901 40 / 2
	06	517 821 98	Resilient sleeve	96	InternBDB: 31 / 55 x 60 / 341 948 40 \| InternKon: 919 901 40 / 4
	07	474 837 40	Spanner	1	InternKon: 925 213 40 / 2
	08	376 792 40	Jaw	1	InternKon: 925 213 40 / 1
	09	324 969 40	Compound (2 LBS) (1,3 kg.)	-2	InternBDB: GM 519 8563 \| InternKon: 919 900 40 / 5
	\|$$13	793 613 73	Slew ring - mounting kit fig-nos. 02-08	-2	InternBDB: E-ST
	\|$$14	794 773 73	Slew ring - mounting kit (cold weather design) fig-nos. 02-08	-2	InternBDB: E-ST

Komatsu PC3000-6 S/N 46174 parts catalog PDF

SLEW RING ARR. (485-1101b) in PC3000-6 S/N 46174. Diagram image and parts list.
