Diagram image 1 of 4

PC3000-6 S/N 46174

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

PC3000-6 S/N 46174

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

PC3000-6 S/N 46174

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

PC3000-6 S/N 46174

? ? ? ? ? ?

#	Part Number	Partname	Quantity	Options	Reference
?	923 720 40	Oil tank	1	InternKon: 919 902 40 / 9
?	923 710 40	Oil tank weldment	1	InternKon: 923 720 40 / 1
?	933 882 40	Valve block, incl. fig-nos: 04, 05	1	InternKon: 923 720 40 / 2
?	631 091 40	Valve block	1	InternKon: 933 882 40 / 1
?		Pressure relief valve	1	InternBDB: 907 048 40 \| InternKon: 933 882 40 / 2	991-0413
?	910 951 40	Filter cover	4	InternKon: 923 720 40 / 4
?	930 078 40	Cover	4	InternKon: 923 720 40 / 5
?	923 744 40	Cover	1	InternKon: 923 720 40 / 6
?	436 040 40	U-bolt	2	InternKon: 923 720 40 / 7
?	366 504 40	Spring	4	InternBDB: 10x50x107 / 2098 \| InternKon: 923 720 40 / 8
?	910 954 40	Bushing	4	InternKon: 923 720 40 / 9
?	940 730 40	4/2 way directional spool valve	1	InternBDB: 4/2 WEGEVENTIL 02-411976 DG4V 3M 0A-M-KUP5D-H7-60 \| InternKon: 923 720 40 / 55
?	366 509 40	Cover	1	InternKon: 923 720 40 / 11
?	255 694 40	Plug	2	InternBDB: Vsti R 3/8 ED \| InternKon: 923 720 40 / 12
?		Return oil filter	3	InternBDB: 906 469 40 \| InternKon: 923 720 40 / 13	991-0348
?		Filter	1	InternBDB: 440 479 40 \| InternKon: 923 720 40 / 14	090-5586
?	904 748 40	Trap with plug	1	InternBDB: CAVO PN 1016, Typ 106 021 \| InternKon: 923 720 40 / 15
?	180 325 40	Base plate	1	InternBDB: G 342/1 \| InternKon: 923 720 40 / 56
?	514 340 98	Screw	4	InternBDB: M5x30 /912 10.9 \| InternKon: 923 720 40 / 57
?	916 746 40	Gasket	1	InternKon: 923 720 40 / 18
?	907 670 40	Limit switch	1	InternBDB: Schaefer KL-ZES
?	366 508 40	Gasket	1	InternKon: 923 720 40 / 20
?	389 472 40	Gasket	1	InternKon: 923 720 40 / 21
?	440 723 40	Compensator	1	InternKon: 923 720 40 / 22
?	502 119 98	O-ring	4	InternBDB: 269,3x5,7 B NB70 \| InternKon: 923 720 40 / 23
?	942 484 40	Retainer	1	InternKon: 923 720 40 / 58
?	319 132 99	Bolt	2	InternBDB: M6x25 /912 \| InternKon: 923 720 40 / 59
?	304 309 99	Bolt	2	InternBDB: M30x200/931 \| InternKon: 923 720 40 / 26
?	505 449 98	Bolt	4	InternBDB: M24x350/931 10.9 \| InternKon: 923 720 40 / 27
?	307 845 99	Bolt	2	InternBDB: M20x50/933 \| InternKon: 923 720 40 / 28
?	507 025 98	Nut	2	InternBDB: M 6 /985 \| InternKon: 923 720 40 / 65
?	371 459 99	Socket	2	InternBDB: SDS-L12XG 3/8 ISO 08434 \| InternKon: 923 720 40 / 72
?	307 752 99	Bolt	8	InternBDB: M8x20/933 \| InternKon: 923 720 40 / 31
?	516 157 98	Union	2	InternBDB: DDL 12 / 3942 \| InternKon: 923 720 40 / 73
?	307 679 99	Bolt	4	InternBDB: M5x12/933 \| InternKon: 923 720 40 / 33
?	308 874 99	Bolt	4	InternBDB: M16x130/931 \| InternKon: 923 720 40 / 34
?	334 686 99	Nut	6	InternBDB: M20/985 \| InternKon: 923 720 40 / 35
?	515 553 98	Hose assy. DN 10x700	1	InternBDB: DOL 12 /DOL 12 \| InternKon: 923 720 40 / 68
?	316 213 99	Washer	2	InternBDB: 25/6916 \| InternKon: 923 720 40 / 38
?	516 175 98	Union	1	InternBDB: SWRT-L15 / 8434 \| InternKon: 923 720 40 / 69
?	551 987 40	Union	2	InternBDB: Red 15/12-PL OMD \| InternKon: 923 720 40 / 71
?	346 510 99	Lock washer	8	InternBDB: A8/128 \| InternKon: 923 720 40 / 41
?	346 509 99	Lock washer	4	InternBDB: A5/128 \| InternKon: 923 720 40 / 42
?	374 407 99	Union	1	InternBDB: SDS-L15 x M18x1,5 /8434 \| InternKon: 923 720 40 / 43
?	515 820 98	Hose assy. DN 12x530	1	InternBDB: DOL 15 /DOL 15-90 \| InternKon: 923 720 40 / 44
?	907 594 40	Fluid level sensor with swimming ball fig.-nos.: 50, 51	1	InternBDB: 780 / M 14x1,5 Interlog \| InternKon: 923 720 40 / 36
?	511 602 98	Banjo bolt	2	InternBDB: HS10 14x1,5 TN A3CX Din 7643
?	972 009	O-ring	2	InternBDB: 15,88x2,26 NBR
?	940 022 40	Plug	1	InternBDB: M64x2 ED INTERHYDRAU \| InternKon: 923 720 40 / 48
?	374 436 99	Socket	2	InternBDB: L 15 E-G 1/2 /3901 \| InternKon: 923 720 40 / 74
?	515 812 98	Coupling	2	InternBDB: G 1/4 - PC \| InternKon: 923 720 40 / 51
?	180 477 40	Union	1	InternBDB: Vsti G 1/2 ed \| InternKon: 923 720 40 / 52
?	308 670 99	Bolt	4	InternBDB: M20x100 /931 \| InternKon: 923 720 40 / 60
?	308 675 99	Bolt	6	InternBDB: M20x150 /931 \| InternKon: 923 720 40 / 61
?	500 716 40	Flange	1	InternKon: 923 720 40 / 62
?	340 470 99	Disc	12	InternKon: 923 720 40 / 63
?		Return oil filter	1	InternBDB: 906 471 40 \| InternKon: 923 720 40 / 64	991-0350
?	324 741 40	Plug	4	InternBDB: F 26 \| InternKon: 923 720 40 / 75
?	255 694 40	Plug	2	InternBDB: Vsti R 3/8 ED
?	533 989 99	Weld on plate	1	InternBDB: L-AP-K-2 W1 / 3015 \| InternKon: 923 720 40 / 45
?	502 631 98	Clamp Set	5	InternBDB: L-2-G-16 PP / 3015 \| InternKon: 923 720 40 / 46
?	319 132 99	Bolt	2	InternBDB: M 6x25 / 912 \| InternKon: 923 720 40 / 47
?	926 952 40	Strainer	1	InternKon: 923 720 40 / 79
?	534 008 99	Cover plate	3	InternBDB: S-DP-A-4 \| InternKon: 923 720 40 / 10
?	308 599 99	Bolt	6	InternBDB: M 12x105 / 931 \| InternKon: 923 720 40 / 16
?	343 006 99	Washer	6	InternBDB: 13 \| InternKon: 923 720 40 / 17
?	505 058 98	Clamp Set	3	InternBDB: S-4-G-70 PP / 3015 \| InternKon: 923 720 40 / 19
?	504 923 98	Clamp Set	1	InternBDB: S-3-G-32 PP / 3015 \| InternKon: 923 720 40 / 24
?	308 581 99	Bolt	2	InternBDB: M 10x70 \| InternKon: 923 720 40 / 25
?	343 005 99	Washer	2	InternBDB: 10,5 \| InternKon: 923 720 40 / 29
?	534 004 99	Cover plate	1	InternBDB: S-DP-A-3 W1 / 3015 \| InternKon: 923 720 40 / 30
?	511 718 98	Clamp Set	2	InternBDB: S-6-E PA / 3015 \| InternKon: 923 720 40 / 66
?	511 196 98	Cover plate	2	InternBDB: S-DP-A-6 W1 / 3015 \| InternKon: 923 720 40 / 67
?	308 679 99	Bolt	4	InternBDB: M 20x190 \| InternKon: 923 720 40 / 70
?	925 178 40	Guide	1	InternKon: 923 720 40 / 76
?	925 177 40	Extension	1	InternKon: 923 720 40 / 77
?	345 052 99	Cotter pin	3	InternBDB: 6x36 \| InternKon: 923 720 40 / 78
?	302 552 99	Bolt	2	InternBDB: M30x120 / 931 \| InternKon: 919 902 40 / 31
?	502 082 98	Bolt	2	InternBDB: M30x250 /931 \| InternKon: 919 902 40 / 32
?	255 057 40	Washer	4	InternBDB: Ш31 /6916 \| InternKon: 919 902 40 / 29
?	516 041 98	Hose assy. DN 10x400	1	InternBDB: DOL 12 DOL 12-90 \| InternKon: 923 720 40 / 83
?	930 923 40	Plate	1	InternKon: 923 720 40 / 80
?	507 037 98	Nut	7	InternBDB: M10/985 \| InternKon: 923 720 40 / 81
?	340 465 99	Washer	3	InternBDB: 10,5/125 \| InternKon: 923 720 40 / 82
?	942 441 40	Cap	1	InternBDB: 2x175x300 \| InternKon: 923 720 40 / 84
?	340 467 99	Washer	4	InternBDB: 13 DIN00125 \| InternKon: 923 720 40 / 85
?	943 689 40	Cable Cover	1	InternKon: 923 720 40 / 86
?	942 485 40	Angle	1	InternBDB: 100x10x30 \| InternKon: 923 720 40 / 87
?	517 122 98	Washer	2	InternBDB: 10 WN65593840 \| InternKon: 923 720 40 / 88
?	307 777 99	Bolt	2	InternBDB: M10x25 8.8 DIN00933 \| InternKon: 923 720 40 / 89

Komatsu PC3000-6 S/N 46174 parts catalog PDF

MAIN OIL TANK (485-1801b) in PC3000-6 S/N 46174. Diagram image and parts list.
