PC3000-6 S/N 46224

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	960 225 40	Hydr. Cylinder (standard)	1
?	962 431 40	Hydr. Cylinder (cold weather design)	1
?	798 058 73	Cylinder barrel incl. fig-nos. 03,04,06,30	1
?		Cylinder barrel	1
?	627 597 40	Freeze-in bush	2
?	004 860 98	Grease nipple	3
?	792 115 73	Piston rod assy. incl. fig-nos. 04,06,08, 30	1
?		Piston rod	1
?	926 856 40	Sealing flange assy. incl. fig-nos. 10-12	1
?		Flanged bush	1
?	926 867 40	Bearing bush (no field repair item)	1
?	342 676 99	Circlip	1
?	481 006 40	Piston	1
?	948 401 40	Groove nut	1
?	324 910 40	Piston guide strap	2
?	950 377 40	Piston guide ring	3
?	200 299 40	O-ring	1
?	635 671 40	Seal ring	1
?	502 005 98	O-ring	1
?	270 354 40	Support ring	2
?	517 557 98	O-ring	1
?	907 658 40	Support ring	1
?	7075111300	Rod seal	1
?	7075611760	Dust seal	1
?	354 277 99	Feather key	1
?	319 309 99	Bolt (standard)	12
?	500 565 98	Bolt (cold weather design)	12
?	7075111400	Buffer ring	1
?	947 184 40	Threaded pin	1
?	907 016 40	Seal ring	4
?	011 799 79	Snap ring	1
?	780 454 73	Seal kit - piston consist. of fig-nos: 16-21	-2
?	797 947 73	Seal kit - piston rod consist. of fig-nos: 22-25,28	-2
?			-2
?			-2
?			-2
?			-2
?			-2
?			-2
?			-2
?			-2
