Diagram image 1 of 4

PC4000-6 S/N 08164

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

PC4000-6 S/N 08164

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

PC4000-6 S/N 08164

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

PC4000-6 S/N 08164

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	915 247 40	Hydraulic pump assy.	1
?	919 597 40	Hydraulic pump assy. adjusted for a working altitude of 1600m	1
?	919 598 40	Hydraulic pump assy. adjusted for a working altitude of 4200m	1
?	767 051 73	Piston housing	2
?	767 052 73	Cover	2
?	767 053 73	Nozzle	1
?	319 540 99	Bolt	16
?	767 054 73	O-ring	2
?	767 055 73	Support ring	2
?	964 770	Plug	4
?	767 039 73	Plug	5
?	767 429 73	Gasket to fig.-no. 09	-2
?	767 056 73	Plug	2
?	319 248 99	Bolt	8
?	767 057 73	Threaded pin	6
?	767 058 73	Plug	8
?	511 561 98	O-ring	10
?	313 405 99	Plug	2
?	767 061 73	Roller	2
?	767 062 73	Piston	1
?	767 063 73	Piston	2
?	767 064 73	ring	2
?	767 065 73	Support ring	2
?	767 066 73	O-ring	1
?	767 067 73	O-ring	2
?	767 068 73	Spring housing	2
?	767 069 73	Spring plate	2
?	767 070 73	Spring	1
?	767 071 73	Spring	1
?	767 072 73	Adjustment	2
?	767 939 73	Nozzle	1
?	767 073 73	Spring	1
?	767 074 73	Spring	1
?	763 523 73	Pilot valve assy	1
?	767 936 73	Nut	2
?	768 978 73	O-ring	4
?	767 935 73	Nut	2
?	767 934 73	Treaded pin	1
?	319 337 99	Bolt	8
?	768 979 73	Piston housing	1
?	767 056 73	Bolt	5
?	767 429 73	Gasket to fig.-no. 38	-2
?	767 092 73	O-ring	2
?	514 917 98	O-ring	2
?	767 933 73	Set piston	1
?	766 693 73	Bushing	1
?	767 085 73	Guide shoe	1
?	767 938 73	Spring	1
?	767 937 73	Threaded pin	1
?	768 980 73	Piston housing	1
?	763 522 73	Pilot valve assy	1
?	767 127 73	Bolt	2
?	767 431 73	Gasket to fig.-no. 48	-2
?	766 694 73	Valve assy.	1
?	766 695 73	Valve housing	1
?	767 039 73	Plug	3
?	767 429 73	Gasket to fig.-no. 52	-2
?	767 127 73	Plug	2
?	767 431 73	Gasket to fig.-no. 53	-2
?	767 092 73	O-ring	4
?	767 093 73	O-ring	1
?	509 812 98	Bolt	2
?	769 128 73	Breaking plug	3
?	999 046	Breaking plug	3
?	767 095 73	Breaking plug	2
?	319 150 99	Bolt	2
?	766 696 73	Non-return valve	1
?	345 040 99	Dowel sleeve	1
?	766 697 73	Non return valve mounting kit	1
?	767 106 73	O-ring	1
?	509 633 98	Threaded pin	1
?	363 539 99	Ball	1
?	363 424 99	Ball	2
?	767 098 73	Eccentric stud	1
?	756 820 73	Needle cage	2
?	767 099 73	Lever	1
?	767 100 73	Parallel pin	1
?	767 101 73	Sleeve	1
?	767 102 73	Bolt	1
?	767 103 73	Union	2
?	215 390 99	Pipe Ш 8 Bulk ware, state length required	-2
?	767 104 73	Union	1
?	767 105 73	Plug	1
?	767 942 73	Plug	1
?	767 943 73	Plug	1
?	514 919 98	O-ring	1
?	767 945 73	Sliding ring	1
?	766 698 73	Indicator assy	1
?	350 902 99	Grove drive stud	2
?	319 417 99	Bolt	1
?	766 699 73	Pointer	1
?	766 700 73	Seal	1
?	767 118 73	Scale	1
?	766 701 73	Threaded pin	1
?	767 120 73	O-ring	1
?	767 121 73	Quad-ring	1
?	766 702 73	Pivot	1
?	767 124 73	Joint part	1
?	345 370 99	Dowel sleeve	1
?	964 736	Breaking plug	1
?	767 901 73	Plug	1
?	767 902 73	Plug	1
?	767 904 73	Cover	1
?	319 140 99	Bolt	3
?	767 903 73	Plug	1
?	767 900 73	Plug	1
?	767 125 73	Pilot valve	1
?	766 703 73	Pump housing	1
?	767 127 73	Plug	5
?	767 431 73	Gasket to fig.-no. 122	-2
?	767 128 73	Plug	3
?	767 129 73	Thread pin assy.	1
?	514 913 98	O-ring	1
?	766 704 73	Power unit	1
?	763 177 73	O-ring	1
?	763 178 73	O-ring	2
?	767 056 73	Plug	3
?	767 132 73	Dummy flange assy.	1
?	767 896 73	Housing	1
?	319 340 99	Bolt	8
?	514 916 98	O-ring	1
?	767 897 73	Cover assy.	1
?	307 822 99	Bolt	4
?	767 930 73	Cover	1
?	767 899 73	Plug	4
?	767 892 73	Reducing union	1
?	767 893 73	Seal	1
?	767 096 73	Plug	1
?	767 923 73	Feather key	1
?	342 555 99	Ring	2
?	767 922 73	Idler	1
?	342 690 99	Ring	1
?	768 981 73	Sealing flange	1
?	766 715 73	Ring	1
?	000 224 98	O-ring	1
?	766 706 73	Drive shaft	1
?	768 982 73	Supporting disc	1
?	767 924 73	Bearing	1
?	342 569 99	Ring	1
?	767 920 73	Shim washer	2
?	767 921 73	Shim washer	2
?	767 926 73	Bolt	2
?	767 912 73	Sliding block	1
?	767 911 73	Pivot	1
?	342 532 99	Ring	1
?	767 919 73	Slider	1
?	767 910 73	Balancer	1
?	767 916 73	Segment	4
?	766 707 73	Piston / guide shoe	9
?	767 913 73	Plate	1
?	767 915 73	Spacer block	4
?	319 424 99	Bolt	8
?	766 708 73	Ball	1
?	767 926 73	Spring	20
?	319 429 99	Bolt	6
?	768 983 73	Cylinder with bushing	1
?	767 908 73	Distribution plate	1
?	766 710 73	Throttle screw	1
?	767 925 73	Bearing	1
?	767 918 73	Bushing	2
?	767 410 73	O-ring	1
?	768 984 73	Adjustment assy.	1
?	512 978 98	Bolt	4
?	767 409 73	O-ring	1
?	767 397 73	Dummy flange	1
?	766 713 73	Sealing bush	1
?	766 714 73	Wheel	1
?	766 717 73	O-ring	1
?	342 676 99	Circlip	1
?	767 929 73	Thread pin	1
?	318 914 99	Screw	4
?	766 712 73	Seal kit pump without valves concist. of fig no.33,39,40 98,99,104,107,108,125,127 128,134,153,182,185,189	1
?	767 160 73	Seal kit, pilot valve	1
?	767 795 73	Seal kit adjustment assy.	1
?	767 311 73	Seal kit, pilot valve concist. of fig no 06,07,09 10,13,14,20,21,22	1
?	767 312 73	Seal kit valve concist. of fig no. 52,53,54 55,62,20,21	1

Komatsu PC4000-6 S/N 08164 parts catalog PDF

VARIABLE DISPLACEMENT PUMP (991-0357a) in PC4000-6 S/N 08164. Diagram image and parts list.
