Diagram image 1 of 2

PC5500-6 S/N 15024

? ? ? ? ? ? ? ? ? ? ? ? ?

PC5500-6 S/N 15024

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Reference
?		Lighting equipment	-2	515-2105i
?		Battery cables	-2	515-2130e
?		Cables oil tank	-2	515-2144j
?		Cables - tank sensor	-2	515-2139d
?		Electr. parts - ladder	-2	515-2143e
?		Electr. parts - air intake	-2	515-2156c
?		Electr. parts - movement signal	-2	515-2152d
?		Electric - cab support	-2	515-2135m
?		Cables - control blocks - h.p.-filter	-2	515-2145e
?		Cables - control- and filter plate front	-2	515-2146j
?		Cables - control- and filter plate rear	-2	515-2147j
?		Cables - engine and transmitter	-2	515-2148i
?		Cables - PDG	-2	515-2155c
?	906 801 40	Cable channel 50/50 Bulk ware, state length required	-2
?	916 651 40	Retainer	40
?	307 727 99	Bolt	40
?	896 742 40	Cable channel 110 Bulk ware, state length required	-2
?	514 072 98	Bolt	50
?	350 763 99	Washer	50
?	916 655 40	Holding device	4
?	340 683 99	Washer	40
?	906 413 40	Cable channel 50/100 Bulk ware, state length required	-2
?	916 658 40	Holding device	3
?	906 802 40	Cable channel 110/150 Bulk ware, state length required	-2
?	910 704 40	Holding device	16
?	916 656 40	Holding device	2
?	916 657 40	Holding device	2
