Diagram image 1 of 4

PC5500-6 S/N 15024

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

PC5500-6 S/N 15024

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

PC5500-6 S/N 15024

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

PC5500-6 S/N 15024

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	655 564 40	Hydro pump	1
?	763 522 73	Pilot valve assy	1
?	319 540 99	Bolt	16
?	767 054 73	O-ring	2
?	767 055 73	Support ring	2
?	964 770	Plug	3
?	767 039 73	Plug	4
?	767 056 73	Plug	2
?	319 248 99	Bolt	8
?	767 058 73	Plug	8
?	511 561 98	O-ring	10
?	767 065 73	Support ring	2
?	767 066 73	O-ring	2
?	767 067 73	O-ring	6
?	763 523 73	Pilot valve assy	1
?	767 075 73	Nut	2
?	767 076 73	O-ring	4
?	767 077 73	Nut	2
?	767 078 73	Treaded pin	1
?	320 153 99	Bolt	8
?	767 079 73	Piston housing	1
?	767 080 73	O-ring	2
?	767 081 73	O-ring	2
?	767 083 73	Set piston	1
?	766 693 73	Bushing	1
?	767 085 73	Guide shoe	1
?	767 086 73	Spring	1
?	767 087 73	Threaded pin	1
?	767 088 73	Piston housing	1
?	767 127 73	Bolt	2
?	767 089 73	Bolt	1
?	766 694 73	Valve assy.	1
?	766 695 73	Valve housing	1
?	767 039 73	Plug	3
?	767 127 73	Plug	2
?	767 092 73	O-ring	4
?	767 093 73	O-ring	1
?	509 812 98	Bolt	2
?	769 128 73	Breaking plug	3
?	999 046	Breaking plug	3
?	767 095 73	Breaking plug	2
?	319 150 99	Bolt	2
?	766 696 73	Non return valve	1
?	345 040 99	Dowel sleeve	1
?	766 697 73	Non return valve	1
?	767 106 73	O-ring	1
?	509 633 98	Threaded pin	1
?	363 539 99	Ball	1
?	363 424 99	Ball	2
?	767 098 73	Eccentric stud	1
?	756 820 73	Needle cage	2
?	767 099 73	Lever	1
?	767 100 73	Parallel pin	1
?	767 101 73	Sleeve	1
?	767 102 73	Bolt	1
?	767 103 73	Union	2
?	215 390 99	Pipe Ш 8 Bulk ware, state length required	-2
?	767 104 73	Union	1
?	767 105 73	Plug	1
?	766 698 73	Indicator assy	1
?	350 902 99	Grove drive stud	2
?	319 417 99	Bolt	1
?	766 699 73	Pointer	1
?	766 700 73	Seal	1
?	767 118 73	Scale	1
?	766 701 73	Threaded pin	1
?	767 120 73	O-ring	1
?	767 121 73	Quad-ring	1
?	766 706 73	Pivot	1
?	767 124 73	Joint part	1
?	345 370 99	Dowel sleeve	1
?	767 125 73	Pilot valve	1
?	768 659 73	Pump housing	1
?	767 127 73	Plug	3
?	767 128 73	Plug	3
?	767 129 73	Thread pin	1
?	767 130 73	O-ring	1
?	768 685 73	Power unit	1
?	763 177 73	O-ring	1
?	763 178 73	O-ring	2
?	767 056 73	Plug	3
?	767 397 73	Dummy flange	1
?	767 133 73	Housing	1
?	319 310 99	Bolt	8
?	767 094 73	Plug	2
?	767 135 73	O-ring	1
?	767 136 73	Cover	1
?	319 156 99	Bolt	2
?	340 467 99	Washer	2
?	768 660 73	Throttle Srew	1
?	768 661 73	Throttle Srew	1
?	767 901 73	Throttle Srew	1
?	768 662 73	Throttle Srew	1
?	964 736	Plug	1
?	342 586 99	Ring	1
?	768 666 73	Sealing flange	1
?	514 914 98	Ring	1
?	516 067 98	O-ring	1
?	767 140 73	Drive shaft	1
?	769 130 73	Bearing	1
?	342 566 99	Ring	1
?	767 927 73	Bolt	2
?	768 671 73	Sealing bush	1
?	767 144 73	Sliding block	1
?	767 145 73	Pivot	1
?	342 528 99	Ring	1
?	767 146 73	Slider	1
?	767 147 73	Balancer	1
?	767 148 73	Segment	4
?	769 131 73	Piston / guide shoe	9
?	769 132 73	Plate	1
?	767 151 73	Spacer block	4
?	319 422 99	Bolt	8
?	768 665 73	Ball	1
?	768 673 73	Spring package	1
?	768 668 73	Washer	1
?	768 672 73		1
?	768 674 73	Washer	1
?	768 667 73	Washer	1
?	768 663 73	Cylinder with bushing	1
?	769 134 73	Distribution plate	1
?	319 140 99	Screw	6
?	769 135 73	Bearing	1
?	767 159 73	Bushing	2
?	767 410 73	O-ring	1
?	769 136 73	Adjustment assy.	1
?	512 978 98	Bolt	4
?	767 409 73	O-ring	1
?	516 066 98	O-ring	1
?	768 676 73	Seal kit pump without valves concist. of fig no.33,39,40 104,107,108,125,127,128,134 153,182	1
?	767 160 73	Seal kit, pilot valve fig. no. 120	1
?	767 164 73	Seal kit adjustment assy. fig. no. 183	1
?	767 311 73	Seal kit, pilot valve concist. of fig no 06,07,09 10,13,14,20,21,22	1
?	767 312 73	Seal kit valve concist. of fig no. 52,53,54 55,,65,20,21	1

Komatsu PC5500-6 S/N 15024 parts catalog PDF

HYDRAULIC PUMP (991-0263) in PC5500-6 S/N 15024. Diagram image and parts list.
