01 |
907 321 40
|
Union |
4 |
InternBDB: GE 22-PL / 7/8-14 UNF OMD | InternKon: 918 815 40 / 16
|
|
|
|
02 |
551 140 40
|
Socket |
2 |
InternBDB: Red 22/18-PL OMD | InternKon: 918 815 40 / 15
|
|
|
|
03 |
374 409 99
|
Socket |
6 |
InternBDB: SDS-L 22XM 26x1,5 -TYPE E-M / ISO 08434 | InternKon: 918 815 40 / 10
|
|
|
|
04 |
654 892 40
|
Union |
6 |
InternBDB: GE 18-PL / 1/2 NPT OMD | InternKon: 918 815 40 / 14
|
|
|
|
05 |
655 294 40
|
Union |
4 |
InternBDB: GE 22 L 3/4 NPT OMD | InternKon: 918 815 40 / 17
|
|
|
|
06 |
653 525 40
|
Hose assy., with fire protection coating, DN 20x840 |
2 |
InternBDB: DOL 22 /DOL 22-90 | InternKon: 918 815 40 / 7
|
|
|
|
07 |
518 208 98
|
Hose assy., with fire protection coating, DN 20x3000 |
2 |
InternBDB: DOL 22 /DOL 22-90 | InternKon: 918 815 40 / 8
|
|
|
|
08 |
518 029 98
|
Hose assy., with fire protection coating, DN 16x450 |
2 |
InternBDB: DOL 18 /DOL 18-90 | InternKon: 918 815 40 / 6
|
|
|
|
09 |
307 800 99
|
Bolt |
8 |
InternBDB: M12x20 /933 | InternKon: 918 815 40 / 18
|
|
|
|
10 |
343 112 99
|
Lock washer |
8 |
InternBDB: 12 /127 | InternKon: 918 815 40 / 19
|
|
|
|
11 |
518 028 98
|
Hose assy., with fire protection coating, DN 16x400 |
2 |
InternBDB: DOL 18 /DOL 18-90 | InternKon: 918 815 40 / 5
|
|
|
|
12 |
770 563 73
|
Pump |
1 |
InternBDB: Cummins R 2000-24
|
|
|
|
13 |
518 209 98
|
Hose assy., with fire protection coating, DN 20x3850 |
2 |
InternBDB: DOL 22 /DOL 22-90 | InternKon: 918 815 40 / 9
|
|
|
|
14 |
518 210 98
|
Hose assy., with fire protection coating, DN 20x3760 |
1 |
InternBDB: DOL 22 /DOL 22-90 | InternKon: 918 815 40 / 12
|
|
|
|
15 |
518 211 98
|
Hose assy., with fire protection coating, DN 20x4250 |
1 |
InternBDB: DOL 22 /DOL 22-90 | InternKon: 918 815 40 / 13
|
|
|
|
16 |
516 160 98
|
Socket |
10 |
InternBDB: SWE-L 22/ ISO 08434 | InternKon: 918 815 40 / 11
|
|
|
|
17 |
517 599 98
|
Socket |
4 |
InternBDB: EVGE18-L 1/2 NPT / 01157699 | InternKon: 918 815 40 / 25
|
|
|
|
18 |
634 298 40
|
Union |
4 |
InternBDB: GR 22 / 18-L/OMD / 65593240 | InternKon: 918 815 40 / 26
|
|
|
|
20 |
896 669 40
|
Level-probe |
4 |
InternBDB: Bedia 425031 3/8Nptf | InternKon: 915 200 40 / 99
|
|
|
|
25 |
768 441 73
|
Bypass filter (Diesel Engine) |
4 |
InternBDB: Cummins 388 93 11
|
|
|
|
26 |
918 814 40
|
Oilmanagement System |
1 |
InternBDB: Eliminator-Filter, Reserve-System, Centinel
|
|
|
|
26 |
944 845 40
|
Oilmanagement System, without Centinel |
1 |
InternBDB: Eliminator-Filter, Reserve-System
|
|
|
|
27 |
792 330 73
|
Sludge Collecting Paper |
20 |
InternBDB: Cummins 339 35 92
|
|
|
|
40 |
907 565 40
|
Fluid level indicator with swimming ball inclusive fig.no. 41 a. 42 450 mm lg. |
2 |
InternKon: 915 200 40 / 2
|
|
|
|
41 |
972 099
|
O-ring |
4 |
InternBDB: 15,88x2,62
|
|
|
|
42 |
511 602 98
|
Banjo bolt |
4 |
InternBDB: HS10 / 14x1,5 TN A3CX / DIN 7643
|
|
|
|
45 |
501 584 98
|
Weld on plate |
10 |
InternBDB: L-AP-K-4 / 3015 | InternKon: 918 815 40 / 20
|
|
|
|
46 |
511 857 98
|
Cover plate |
10 |
InternBDB: L-4 / 3015 | InternKon: 918 815 40 / 21
|
|
|
|
48 |
504 900 98
|
Clamp set |
20 |
InternBDB: L-4-G-28 / 3015 | InternKon: 918 815 40 / 23
|
|
|
|
49 |
308 537 99
|
Bolt |
20 |
InternBDB: M 6x45 / 8.8 / DIN 931 | InternKon: 918 815 40 / 24
|
|
