PC4000-6E S/N 08202

01 02 03 04 05 06 07 07 08 09 10 10 11 12 13 14 14 15 15 16 17 18 19 20 21 22 23 23 24 25 26 27 28 28 29 29 30 31 32 33 33 34 35 36 37 38 39 40 42 43 46 47 51 52 63 64 65 66 67 70

#	Part Number	Partname	Quantity	Options	Reference
01	907 678 40	Lube pump station	1	InternBDB: HL-A 07.007 BL.55 Index A 609-29233-1
02		Lube pump	1	InternBDB: 509-32178-1 /769 397 73 \| InternKon: HL-A 07.007 BL.55 / 5	991-0266b
03	794 266 73	Case assy.	1	InternBDB: 509-32544-1 \| InternKon: HL-A 07.007 BL.55 / 1
04	794 351 73	Cover assy.	1	InternBDB: 409-70588-1 \| InternKon: HL-A 07.007 BL.55 / 3
05	696 293 73	Seal ca. 1900 lg.	1	InternBDB: 116-35196-2 \| InternKon: HL-A 07.007 BL.55 / 4
06	770 401 73	Union	1	InternBDB: 223-14187-6 EGE20-S G 1/2A-ED/A3C \| InternKon: HL-A 07.007 BL.55 / 52
07	769 894 73	Elbow union	2	InternBDB: WE 20-S 3/4 NPT /223-13620-2 \| InternKon: HL-A 07.007 BL.55 / 7
08	374 418 99	Socket	1	InternBDB: EVGE 20-S G 3/4 C \| InternKon: HL-A 07.007 BL.55 / 8
09	698 303 73	Filter assy.	1	InternBDB: 084 004 \| InternKon: HL-A 07.007 BL.55 / 9
10	372 052 99	Union	2	InternBDB: EVL 20-SC 223-13761-7 \| InternKon: HL-A 07.007 BL.55 / 10
11	372 971 99	Union	1	InternBDB: KOR 20/10-SC \| InternKon: HL-A 07.007 BL.55 / 11
12	793 996 73	Union	1	InternBDB: EL 10-S 223-14190-2 \| InternKon: HL-A 07.007 BL.55 / 12
13	770 107 73	Union	1	InternBDB: GE 20-S G 3/4 223-12359-6 \| InternKon: HL-A 07.007 BL.55 / 15
14	372 869 99	Union	2	InternBDB: MAVE 10-S G 1/4 C 223-14268-2 \| InternKon: HL-A 07.007 BL.55 / 14
15	794 268 73	Adapter	2	InternBDB: 910 000-E 1/2 NPTI x G 3/4 \| InternKon: HL-A 07.007 BL.55 / 6
16	698 321 73	Pressure gauge 0-400 bar	1	InternBDB: Ш 63 234-13132-7 \| InternKon: HL-A 07.007 BL.55 / 16
17		Union	1	InternBDB: EVW 10-S 223-14171-8 \| InternKon: HL-A 07.007 BL.55 / 13
18	794 350 73	Union	1	InternBDB: XEW 20-S 223-14171-7 \| InternKon: HL-A 07.007 BL.55 / 63
19	372 981 99	Union	1	InternBDB: KOR 25/20-S \| InternKon: HL-A 07.007 BL.55 / 21
20	371 264 99	Nut	1	InternBDB: 223-12373-7 M 25 S \| InternKon: HL-A 07.007 BL.55 / 23
21	371 235 99	Olive	1	InternBDB: 223-12296-4 D 25 S \| InternKon: HL-A 07.007 BL.55 / 24
22	769 395 73	Grease coupling	1	InternBDB: 226-13690-9/60 6511 620 023 \| InternKon: HL-A 07.007 BL.55 / 22
23	215 219 99	Pipe Ш 20	-2	InternBDB: 105-35134-1 \| InternKon: HL-A 07.007 BL.55 / 42
24	768 506 73	Union	1	InternBDB: GE 20-S G 1/2 C 223-12360-6 \| InternKon: HL-A 07.007 BL.55 / 27
25	769 879 73	2/2-Directional solenoid valve	1	InternBDB: 235-13185-1 \| InternKon: HL-A 07.007 BL.55 / 25
26	766 876 73	Plug	1	InternBDB: 236-13869-1 \| InternKon: HL-A 07.007 BL.55 / 26
27	768 507 73	Clamp	2	InternBDB: 226-13058-3 \| InternKon: HL-A 07.007 BL.55 / 19
28	768 508 73	Elbow union	2	InternBDB: SWVE 12-L G 3/8 C 223-13669-3 \| InternKon: HL-A 07.007 BL.55 / 31
29	215 424 99	Pipe Ш 12	-2	InternBDB: 105-35134-3 \| InternKon: HL-A 07.007 BL.55 / 41
30	372 899 99	Union	1	InternBDB: KOR 15/12-LC \| InternKon: HL-A 07.007 BL.55 / 32
31	208 895 40	Sleeve	1	InternBDB: 980058-E \| InternKon: HL-A 07.007 BL.55 / 33
32	208 896 40	Protection cap	1	InternBDB: 968035-E \| InternKon: HL-A 07.007 BL.55 / 34
33	769 396 73	Clamp	1	InternBDB: 226-13771-7 \| InternKon: HL-A 07.007 BL.55 / 35
34	371 259 99	Nut	1	InternBDB: AS 12 M 12 /223-12373-2 \| InternKon: HL-A 07.007 BL.55 / 36
35	513 285 98	Socket	1	InternBDB: EVGE 10-S G 1/4 C 223-13681-1 \| InternKon: HL-A 07.007 BL.55 / 37
36	769 875 73	2/2-Directional solenoid valve	1	InternBDB: 235-13181-8 \| InternKon: HL-A 07.007 BL.55 / 38
37	318 603 99	Screw	2	InternBDB: M6x16 /912 200-13022-4 \| InternKon: HL-A 07.007 BL.55 / 44
38	490 155 40	Sleeve	1	InternBDB: 980057-E \| InternKon: HL-A 07.007 BL.55 / 39
39	368 235 40	Protection cap	1	InternBDB: 968036-E \| InternKon: HL-A 07.007 BL.55 / 40
40	907 049 40	Pressure measuring transducer 0-500bar	1	InternBDB: 234-13169-6 1-11V \| InternKon: HL-A 07.007 BL.55 / 17
42	794 330 73	Junction box assy.	1	InternBDB: E 631 664-29366-1 \| InternKon: HL-A 07.007 BL.55 / 43
43	764 658 73	Filter	1	InternBDB: BF8-R 1/4 235-13029-8 \| InternKon: HL-A 07.007 BL.55 / 28
46	698 316 73	Filter element	1	InternBDB: Linco 69524
47	371 241 99	Olive	1	InternBDB: D 12-US 223-12296-1 \| InternKon: HL-A 07.007 BL.55 / 47
51	794 083 73	Dipstick	1	InternBDB: 409-70376-1 \| InternKon: HL-A 07.007 BL.55 / 18
52	794 529 73	Level indicator aasy. analog	1	InternBDB: Lincoln 529-36999-9 \| InternKon: HL-A 07.007 BL.55 / 30
63	794 353 73	Sleeve	1	InternBDB: 304-16058-1 G3/4x45 \| InternKon: 529-36999-8 / 1
64	794 338 73	Seal ring	1	InternBDB: 35x25x2 934035- \| InternKon: 529-36999-8 / 2
65	794 339 73	Socket	1	InternBDB: 222-12047-8 G3/4xG1/2 \| InternKon: 529-36999-8 / 3
66	940 734 40	Sensor kapazitiv assy.	1	InternBDB: 535-34229-2 eingestellt fьr stationдres FaЯ \| InternKon: 529-36999-8 / 4
67	794 521 73	Cable assy.	1	InternBDB: 113-35258-4
70	794 390 73	Solenoid 24V	1	InternBDB: Hawe 4704 814100/4900 117/1-24V

Komatsu PC4000-6E S/N 08202 parts catalog PDF

LUBE PUMP STATION, FILLING CONNECTION (991-0554d) in PC4000-6E S/N 08202. Diagram image and parts list.
