01 |
949 110 40
|
Manipulator assy. |
1 |
InternBDB: FSG 3522 S 10-000M004D / TL FS-u/XA/XB/1/2/Ka/02 | InternKon: 947 959 40 / 10
|
|
|
|
02 |
767 579 73
|
Axle |
1 |
InternBDB: 3522 S 10-00:14 | InternKon: 3522 S 10-000M004D / 1
|
|
|
|
03 |
767 580 73
|
Pedal |
1 |
InternBDB: 3522 S 10-00:10000 | InternKon: 3522 S 10-000M004D / 2
|
|
|
|
04 |
767 581 73
|
Coating |
2 |
InternBDB: 3522 S 10-00:07 | InternKon: 3522 S 10-000M004D / 3
|
|
|
|
05 |
500 915 98
|
Washer |
4 |
InternBDB: 10x16x0.2/988 | InternKon: 3522 S 10-000M004D / 6
|
|
|
|
06 |
325 131 99
|
Threaded pin |
1 |
InternBDB: M6x12 / 913 | InternKon: 3522 S 10-000M004D / 8
|
|
|
|
07 |
307 703 99
|
Bolt |
1 |
InternBDB: M5x12 / 933 | InternKon: 3522 S 10-000M004D / 9
|
|
|
|
08 |
514 481 98
|
Bolt |
6 |
InternBDB: M5x8 / 963 | InternKon: 3522 S 10-000M004D / 10
|
|
|
|
09 |
793 096 73
|
Bearing support assy. |
2 |
InternBDB: 3522 S 50.300 | InternKon: 3522 S 10-000M004D / 11
|
|
|
|
10 |
|
Friction bearing |
6 |
InternBDB: EL101-0009 | InternKon: 3522 S 10-000M004D / 12
|
|
|
|
11 |
|
Threaded pin |
1 |
InternBDB: M6x5 / 913 | InternKon: 3522 S 10-000M004D / 15
|
|
|
|
12 |
768 438 73
|
Hoist Transmitter X-Axis |
2 |
InternBDB: 3522 S 10:00F6X | InternKon: 3522 S 10-000M004D / 13
|
|
|
|
13 |
770 720 73
|
Hoist Transmitter |
1 |
InternBDB: 3495E01-001.027 | InternKon: 3522 S 10-000M004D / 14
|
|
