03 |
|
Electric motor |
1 |
InternBDB: 933 319 40 (bei Ersatz ist E-Motor 944 765 40 zu liefern) | InternKon: 946 400 40 / 1
|
991-0859 |
|
|
04 |
930 212 40
|
Power frame |
1 |
InternKon: 945 723 40 / 3
|
|
|
|
06 |
|
Coupling |
1 |
InternBDB: 907 174 40 | InternKon: 945 723 40 / 6
|
991-0427 |
|
|
07 |
931 013 40
|
Air outlet |
1 |
InternKon: 945 723 40 / 7
|
|
|
|
08 |
931 120 40
|
Console PDG |
2 |
InternKon: 945 723 40 / 8
|
|
|
|
09 |
931 113 40
|
Protection casing |
1 |
InternKon: 945 723 40 / 9
|
|
|
|
10 |
903 780 40
|
Plate |
4 |
InternKon: 945 723 40 / 10
|
|
|
|
11 |
936 020 40
|
Spanner |
4 |
InternKon: 945 723 40 / 11
|
|
|
|
12 |
936 021 40
|
Spanner |
2 |
InternKon: 945 723 40 / 12
|
|
|
|
13 |
504 859 98
|
Bolt |
6 |
InternBDB: M20x100 10.9 DIN00933 | InternKon: 945 723 40 / 13
|
|
|
|
14 |
504 662 98
|
Nut |
6 |
InternBDB: M20 10 DIN00934 | InternKon: 945 723 40 / 14
|
|
|
|
15 |
517 968 98
|
Resilient sleeve |
4 |
InternBDB: 37/80x90 WN34194840 | InternKon: 945 723 40 / 15
|
|
|
|
16 |
518 260 98
|
Bolt |
4 |
InternBDB: M36x210 10.9 DIN00931 | InternKon: 945 723 40 / 16
|
|
|
|
17 |
501 124 98
|
Nut |
8 |
InternBDB: M36 10 DIN00934 | InternKon: 945 723 40 / 17
|
|
|
|
18 |
924 374 40
|
Washer |
1 |
InternKon: 945 723 40 / 18
|
|
|
|
19 |
307 924 99
|
Bolt |
1 |
InternBDB: M30x60 8.8 DIN00933 | InternKon: 945 723 40 / 19
|
|
|
|
20 |
504 304 98
|
Bolt |
10 |
InternBDB: M18x40 10.9 DIN00933 | InternKon: 945 723 40 / 20
|
|
|
|
23 |
307 804 99
|
Bolt |
24 |
InternBDB: M12x30 8.8 DIN00933 | InternKon: 945 723 40 / 23
|
|
|
|
24 |
334 600 99
|
Nut |
24 |
InternBDB: M12 8 DIN00985 | InternKon: 945 723 40 / 24
|
|
|
|
25 |
515 291 98
|
Bolt |
4 |
InternBDB: M36x210 10.9 DIN00931 | InternKon: 945 723 40 / 25
|
|
|
|
26 |
502 507 98
|
Bolt |
4 |
InternBDB: M30x200 10.9 DIN00931 | InternKon: 945 723 40 / 26
|
|
|
|
27 |
576 698 40
|
Resilent sleeve |
8 |
InternBDB: 31/55x95 WN34194840 | InternKon: 945 723 40 / 27
|
|
|
|
28 |
623 505 40
|
Moulding material |
2 |
InternBDB: 25x40x635 | InternKon: 945 723 40 / 28
|
|
|
|
29 |
607 619 40
|
Moulding material |
1 |
InternBDB: 40x40x2200 | InternKon: 945 723 40 / 29
|
|
|
|
30 |
307 582 99
|
Bolt |
4 |
InternBDB: M16x60 10.9 DIN00933 | InternKon: 945 723 40 / 30
|
|
