Diagram image 1 of 2

PC4000-6 S/N 08195

01 02 03 03 03 04 05 05 06 06 07 08 09 10 11 12 13 14 15 15 16 16 17 18 19 19 19 20 21 21 22 22 23 24 25 26 27 28 28 29 29 30 31 32 45 45 46 47 55 56 57 58 59 60 61 62 63 64 70 71 72 73 74 75 76

PC4000-6 S/N 08195

33 34 34 35 36 37 38 38 39 39 40 41 42 43 44 48 49 50 51 52 53 54

#	Part Number	Partname	Quantity	Options	Reference
01		operator's cab	1	InternBDB: 942 045 40	991-0696g
02	945 800 40	Stage	1	InternBDB: MB \| InternKon: 945 699 40 / 2
03	901 905 40	Adapter plate	4	InternKon: 945 699 40 / 3
04	901 855 40	Absorber	18	InternBDB: TL \| InternKon: 945 699 40 / 4
05	510 728 98	Resilient sleeve 25/45x80	44	InternKon: 945 699 40 / 5
06	308 886 99	Bolt	44	InternBDB: M24x120 /931 10.9 \| InternKon: 945 699 40 / 7
07	512 958 98	Resilient sleeve 13/25x45	72	InternKon: 945 699 40 / 6
08	308 435 99	Bolt	72	InternBDB: M12x85 /931 10.9 \| InternKon: 945 699 40 / 8
09	316 216 99	Washer	72	InternBDB: 13 /6916 \| InternKon: 945 699 40 / 10
10	332 353 99	Nut	72	InternBDB: M 12 /934 \| InternKon: 945 699 40 / 9
11	901 913 40	Grating	1	InternKon: 945 699 40 / 11
12	901 914 40	Grating	1	InternKon: 945 699 40 / 12
13	901 926 40	Grating	1	InternKon: 945 699 40 / 13
14	901 927 40	Grating	1	InternKon: 945 699 40 / 14
15	906 021 40	Grating 40x480x1590	2	InternKon: 945 699 40 / 17
16	317 319 40	Threaded block	18	InternKon: 945 699 40 / 18
17	317 318 40	Wing nut, plastic	8	InternKon: 945 699 40 / 19
18	502 354 98	Bolt	8	InternBDB: M8x40 /963 \| InternKon: 945 699 40 / 20
19	307 757 99	Bolt	22	InternBDB: M8x35 /933 \| InternKon: 945 699 40 / 21
20	346 510 99	Lock washer	10	InternBDB: 8 /128 \| InternKon: 945 699 40 / 22
21	913 139 40	Adaptor plate	2	InternKon: 945 699 40 / 29
22	913 141 40	Adaptor plate	2	InternKon: 945 699 40 / 30
23	307 600 99	Bolt	2	InternBDB: M12x40/933 \| InternKon: 945 699 40 / 23
24	340 467 99	Washer	4	InternBDB: 13/125 \| InternKon: 945 699 40 / 24
25	180 894 40	Plug	2	InternBDB: F 10 \| InternKon: 945 699 40 / 35
26	913 142 40	Angle	2	InternKon: 945 699 40 / 31
27	913 143 40	Angle	2	InternKon: 945 699 40 / 32
28	334 599 99	Nut	12	InternBDB: M8/985 \| InternKon: 945 699 40 / 33
29	340 507 99	Washer	12	InternBDB: 8,4/125 \| InternKon: 945 699 40 / 34
30	308 444 99	Bolt (Standard)	34	InternBDB: M1 6x100 / 931 10.9 \| InternKon: 938 550 40 / 30
31	513 033 98	Bolt (Low Temperature)	34	InternBDB: M1 6x100 / 931 10.9
32	510 730 98	Resilient sleeve 17/30x55	34	InternKon: 938 550 40 / 29
33	655 730 40	Hose Ш13	-2	InternBDB: 13x3,5 Gewebeflex \| InternKon: 938 550 40 / 20
34	007 666 98	Hose clip	3	InternBDB: 1 S 18x12 \| InternKon: 938 550 40 / 21
35	511 015 98	Union	1	InternBDB: T-L 12 ISO 08434 \| InternKon: 938 550 40 / 22
36	906 347 40	Olive	3	InternBDB: ES-4 L 12 \| InternKon: 938 550 40 / 23
37	371 274 99	Union nut	3	InternBDB: N-L 12 ISO 08434 \| InternKon: 938 550 40 / 32
38	599 165 40	Pipe Ш12	-2	InternBDB: 12x1,5 \| InternKon: 938 550 40 / 33
39	501 796 98	Union	2	InternBDB: S-L 18/ISO 08434 \| InternKon: 938 550 40 / 34
40	516 816 98	Hose DN16x6000	2	InternBDB: DOL18-90 WN 34195140 \| InternKon: 938 550 40 / 35
41	500 033 98	Clamp set	5	InternBDB: L-2-R-18 PP / 3015 \| InternKon: 938 550 40 / 36
42	319 132 99	Bolt	10	InternBDB: M 6x25 / 912 \| InternKon: 938 550 40 / 37
43	500 980 98	Clamp set	10	InternBDB: L-3-R-25 PP / 3015 \| InternKon: 938 550 40 / 38
44	319 418 99	Bolt	20	InternBDB: M 6x60 / 912 \| InternKon: 938 550 40 / 39
45	501 111 98	Bolt (Low Temperature)	44	InternBDB: M 24x120 / 913 \| InternKon: 944 870 40 / 7
46	516 576 98	Bolt (Low Temperature)	72	InternBDB: M 12x85 / 913 \| InternKon: 944 870 40 / 8
47	516 577 98	Nut (Low Temperature)	72	InternBDB: M 12 / 934 \| InternKon: 944 870 40 / 9
48	371 276 99	Union nut	2	InternBDB: N-L 18 ISO 08434 \| InternKon: 938 550 40 / 40
49	906 349 40	Olive	2	InternBDB: ES -4 L18 WN 65593940 \| InternKon: 938 550 40 / 41
50	914 702 40	Insulation board	1	InternBDB: 1000 x 1800 \| InternKon: 914 701 40 / 1
51	914 703 40	Insulation board	1	InternBDB: 400 x 1800 \| InternKon: 914 701 40 / 2
52	914 704 40	Insulation board	1	InternBDB: 1000 x 1800 \| InternKon: 914 701 40 / 3
53	515 826 40	Thread pin	20	InternBDB: M 4x25 \| InternKon: 914 701 40 / 4
54	515 452 40	Clip	20	InternBDB: D=70 13 F 0001 \| InternKon: 914 701 40 / 5
55	922 847 40	Rail assy.	1	InternKon: 945 699 40 / 15
56	922 812 40	Rail	1	InternKon: 945 699 40 / 16
57	931 464 40	Rail	1	InternKon: 945 699 40 / 25
58	341 271 99	Trigger snap	2	InternKon: 945 699 40 / 26
59	472 511 99	Chain	-2	InternBDB: 3-5x18,5BK DIN00766 \| InternKon: 945 699 40 / 27
60	191 538 40	Shackle	2	InternBDB: 65 \| InternKon: 945 699 40 / 28
61	518 266 98	Clamp set	26	InternBDB: S-4-R-38 / DIN 3015 \| InternKon: 945 699 40 / 36
62	534 008 99	Cover plate	26	InternBDB: S-DP-A-4 / DIN 3015 \| InternKon: 945 699 40 / 37
63	308 434 99	Bolt	52	InternBDB: M12x115 / 931 \| InternKon: 945 699 40 / 38
64	509 310 98	Locking plate	26	InternBDB: SI-6 \| InternKon: 945 699 40 / 39
70	930 037 40	Rail pipe	1	InternKon: 922 847 40 / 2
71	930 031 40	Catch	1	InternKon: 922 847 40 / 3
72	517 697 98	Pin	1	InternBDB: B12 H11x35x29,5 /1444 \| InternKon: 922 847 40 / 4
73	342 045 99	Cotter pin	1	InternBDB: 3x20 /94 \| InternKon: 922 847 40 / 6
74	340 605 99	Washer	1	InternBDB: 12 /1440 \| InternKon: 922 847 40 / 5
75	098 955 40	Ring Ш 35	2	InternKon: 922 847 40 / 7
76	472 688 99	Chain	2	InternBDB: DIN 05686 \| InternKon: 922 847 40 / 8

Komatsu PC4000-6 S/N 08195 parts catalog PDF

OPERATORґS CAB ARR. (355-1904l1) in PC4000-6 S/N 08195. Diagram image and parts list.
