01 |
|
Slewing crane |
1 |
InternBDB: 937 811 40, 937 812 40, 937 813 40
|
991-0695 |
|
|
02 |
921 395 40
|
Lifting beam |
1 |
InternKon: 937 810 40 / 1
|
|
|
|
03 |
302 659 99
|
Bolt |
4 |
InternBDB: M36x300 /931 10.9 | InternKon: 937 810 40 / 4
|
|
|
|
04 |
340 523 99
|
Washer |
4 |
InternBDB: 37 /125 | InternKon: 937 810 40 / 5
|
|
|
|
05 |
308 415 99
|
Bolt |
10 |
InternBDB: M20x115 /931 | InternKon: 937 810 40 / 8
|
|
|
|
06 |
510 740 98
|
Resilient sleeve |
10 |
InternBDB: 21/35x35 | InternKon: 937 810 40 / 9
|
|
|
|
07 |
504 662 98
|
Nut |
10 |
InternBDB: M 20 /934 | InternKon: 937 810 40 / 10
|
|
|
|
08 |
308 882 99
|
Bolt |
2 |
InternBDB: M20x65 /931 | InternKon: 937 810 40 / 11
|
|
|
|
09 |
340 690 99
|
Washer |
2 |
InternBDB: 21 /7349 | InternKon: 937 810 40 / 12
|
|
|
|
10 |
308 611 99
|
Bolt |
8 |
InternBDB: M12x90 /931 | InternKon: 937 810 40 / 13
|
|
|
|
11 |
510 741 98
|
Resilient sleeve |
8 |
InternBDB: 13/25x50 | InternKon: 937 810 40 / 14
|
|
|
|
12 |
340 467 99
|
Washer |
4 |
InternBDB: B Ш13 | InternKon: 937 810 40 / 6
|
|
|
|
13 |
933 494 40
|
Baering |
1 |
InternKon: 937 810 40 / 3
|
|
|
|
14 |
933 935 40
|
Plate |
1 |
InternKon: 937 810 40 / 2
|
|
|
|
15 |
308 459 99
|
Bolt |
6 |
InternBDB: M12x100 /931 10.9 | InternKon: 937 810 40 / 22
|
|
|
|
16 |
334 600 99
|
Nut |
11 |
InternBDB: M 12 /985 Pos. 07,15 | InternKon: 937 810 40 / 15
|
|
|
|
17 |
502 658 98
|
Half clamp |
6 |
InternBDB: S-4-G-56 /3015 | InternKon: 937 810 40 / 18
|
|
|
|
18 |
534 009 99
|
Weld on plate |
3 |
InternBDB: S-AP-A-4 /3015 | InternKon: 937 810 40 / 20
|
|
|
|
19 |
502 965 98
|
Cover plate |
3 |
InternBDB: S-DP-A-4 /3015 | InternKon: 937 810 40 / 21
|
|
|
|
20 |
319 440 99
|
Bolt |
4 |
InternBDB: M12x100 /933 | InternKon: 937 810 40 / 23
|
|
|
|
25 |
515 219 98
|
Hose assy. DN 5x4100 |
1 |
InternKon: 937 811 40 / 3
|
|
|
|
26 |
515 218 98
|
Hose assy. DN 8x4000 |
9 |
InternKon: 937 811 40 / 4
|
|
|
|
27 |
921 551 40
|
Harness assy. |
1 |
InternKon: 943 248 40 / 37
|
|
|
|
28 |
655 651 40
|
Cable protection hose DN 17 |
-2 |
InternBDB: VCSG-17 B | InternKon: 921 551 40 / 2
|
|
|
|
29 |
907 478 40
|
Cable union DN 17 |
1 |
InternBDB: BVNV-P 167 G | InternKon: 921 551 40 / 3
|
|
|
|
30 |
517 328 98
|
Reducing M25/M20 |
1 |
InternBDB: M25x1,5/M20x1,5 DIN 50262 | InternKon: 921 551 40 / 4
|
|
|
|
31 |
907 956 40
|
Cable 4,0 sw |
-2 |
InternKon: 921 551 40 / 5
|
|
|
|
32 |
906 465 40
|
Cable 4,0 ge/gr |
-2 |
InternKon: 921 551 40 / 8
|
|
|
|
33 |
056 072 40
|
Cable sleeve 4,0-10 |
8 |
InternKon: 921 551 40 / 1
|
|
