PC5500-6 S/N 15056

Komatsu parts book diagram for PC5500-6 S/N 15056: CABIN AIR FILTER MODIFICATION

01 02 03 04 05 05 06 06 07 08 08 08 08 09 10 11 12 13 14 15 16 17

	#	Part Number	Partname	Quantity	Options	Reference
	01	944 135 40	Cover	1	InternKon: 944 133 40 / 1
	02	516 092 98	Resilient sleeve	4	InternBDB: 13 /25X 55 /WN 34194840 \| InternKon: 944 133 40 / 2
	03	080 910 40	Air filter	1	InternBDB: FWG 08-0023 / Donaldson \| InternKon: 944 133 40 / 3
	03			-2
	04	940 024 40	Pre-filter	1	InternBDB: H 00-1249 / Donaldson \| InternKon: 944 133 40 / 4
	05	940 025 40	Curved pipe	2	InternBDB: P10-5532 / Donaldson \| InternKon: 944 133 40 / 5
	06	940 023 40	Clamp	2	InternBDB: POO-4307 / Donaldson \| InternKon: 944 133 40 / 6
	07	308 442 99	Bolt	4	InternBDB: M8X85 /DIN 00931 \| InternKon: 944 133 40 / 7
	08	907 310 40	Hose clamp	4	InternBDB: C1-2- 88X25 /DIN 03017 \| InternKon: 944 133 40 / 8
	09	490 694 40	Moulding material	-2	InternBDB: 20X20 NK20 \| InternKon: 944 133 40 / 9
	10	940 716 40	Rubber cord	-2	InternBDB: 20X3 \| InternKon: 944 133 40 / 10
	11	307 760 99	Bolt	3	InternBDB: M8X50 /DIN 00933 \| InternKon: 944 133 40 / 11
	12	510 747 98	Resilient sleeve	3	InternBDB: 8,4/15X 35 /WN 34194840 \| InternKon: 944 133 40 / 12
	13	334 599 99	Nut	4	InternBDB: M8/ 985 \| InternKon: 944 133 40 / 13
	14	340 464 99	Washer	4	InternBDB: B 8,4/ 125 \| InternKon: 944 133 40 / 14
	15	795 352 73	Filter element assy.	1	InternBDB: P18-1054 / Donaldson \| InternKon: 080 910 40 / 2
	16	636 387 40	Strip	2	InternKon: 913 802 40 / 98
	17	636 388 40	Strip	1	InternKon: 913 802 40 / 99

Komatsu PC5500-6 S/N 15056 parts catalog PDF

CABIN AIR FILTER MODIFICATION (515-1925b) in PC5500-6 S/N 15056. Diagram image and parts list.
