358 616 40
|
Hydr.-motor, assy. |
1 |
InternBDB: Brueninghaus A2F 500 W 5Z1-S,Viton 901 056 AT-Nr. 668 848
|
|
|
|
? |
|
Housing |
1 |
InternBDB: 676 047 | InternKon: 98740538000 / 04
|
|
|
|
? |
320 153 99
|
Screw |
8 |
InternBDB: M20x55 /912 10.9 | InternKon: 98740538000 / 10
|
|
|
|
? |
753 168
|
Control plate |
1 |
InternBDB: 601 136 | InternKon: 98740538000 / 05
|
|
|
|
? |
504 747 98
|
O-ring |
1 |
InternBDB: 192x4 Viton 80 Shore | InternKon: 98740538000 / 08
|
|
|
|
? |
345 632 99
|
Pin |
2 |
InternBDB: 10 M6x32 / 6325 | InternKon: 98740538000 / 11
|
|
|
|
? |
973 126
|
Plug |
1 |
InternBDB: vsti M33x2 ed /Viton 636 797 | InternKon: 98740538000 / 12
|
|
|
|
? |
973 127
|
Plug |
1 |
InternBDB: vsti M18x1,5 ed /Viton 647 152 | InternKon: 98740538000 / 13
|
|
|
|
? |
754 498
|
Transmission, assy.
fig-nos: 10-38 |
1 |
InternBDB: 927 228 | InternKon: 98740538000 / 01
|
|
|
|
? |
345 648 99
|
Pin |
1 |
InternBDB: 12 M6x24 / 6325 | InternKon: 97630840500 / 13
|
|
|
|
? |
754 499
|
Centering pin |
1 |
InternBDB: 788 562 | InternKon: 97630840500 / 12
|
|
|
|
? |
753 157
|
Distribution plate |
1 |
InternBDB: 602 124 | InternKon: 97630840500 / 07
|
|
|
|
? |
754 371
|
Spacer screw |
1 |
InternBDB: 941 859 | InternKon: 97630840500 / 16
|
|
|
|
? |
754 372
|
Adjusting ring |
1 |
InternBDB: 941 883 | InternKon: 97630840500 / 15
|
|
|
|
? |
998 637
|
Cylinder |
1 |
InternBDB: 602 086 | InternKon: 97630840500 / 06
|
|
|
|
? |
998 639
|
Spring |
1 |
InternBDB: 678 767 | InternKon: 97630840500 / 14
|
|
|
|
? |
754 373
|
Pivot |
1 |
InternBDB: 795 119 | InternKon: 97630840500 / 08
|
|
|
|
? |
998 929
|
Piston |
7 |
InternBDB: 444 375 | InternKon: 97630840500 / 01
|
|
|
|
? |
|
Spherical bush |
7 |
InternBDB: 900 369 | InternKon: 97630840500 / 05
|
|
|
|
? |
320 332 99
|
Screw |
14 |
InternBDB: M8x20 /6912 | InternKon: 97630840500 / 37
|
|
|
|
? |
754 374
|
Withdrawal plate |
1 |
InternBDB: 737 062 | InternKon: 97630840500 / 09
|
|
|
|
? |
754 494
|
Driving flange |
1 |
InternBDB: 901 668 | InternKon: 97630840500 / 04
|
|
|
|
? |
502 487 98
|
Ball bearing |
2 |
InternBDB: 7322 BUA /628 | InternKon: 97630840500 / 18
|
|
|
|
? |
998 933
|
Race |
1 |
InternBDB: 646 636 | InternKon: 97630840500 / 10
|
|
|
|
? |
504 750 98
|
Roller bearing |
1 |
InternBDB: NJ 222 M / 5412 | InternKon: 97630840500 / 19
|
|
|
|
? |
998 629
|
Shim ring 200x240x1.0 |
1 |
InternBDB: 625 604 | InternKon: 97630840500 / 32
|
|
|
|
? |
998 630
|
Shim ring 200x240x0.5 |
1 |
InternBDB: 625 612 | InternKon: 97630840500 / 33
|
|
|
|
? |
998 631
|
Shim ring 200x240x0.2 |
2 |
InternBDB: 625 647 | InternKon: 97630840500 / 34
|
|
|
|
? |
998 632
|
Shim ring 200x240x0.1 |
1 |
InternBDB: 625 655 | InternKon: 97630840500 / 35
|
|
|
|
? |
998 625
|
Shim ring 110x140x1.0 |
1 |
InternBDB: 432 989 | InternKon: 97630840500 / 28
|
|
|
|
? |
998 626
|
Shim ring 110x140x0.5 |
1 |
InternBDB: 602 183 | InternKon: 97630840500 / 29
|
|
|
|
? |
998 627
|
Shim ring 110x140x0.2 |
2 |
InternBDB: 602 205 | InternKon: 97630840500 / 30
|
|
|
|
? |
998 628
|
Shim ring 110x140x0.1 |
1 |
InternBDB: 486 795 | InternKon: 97630840500 / 31
|
|
|
|
? |
342 572 99
|
Circlip |
1 |
InternBDB: 110x4 /471 | InternKon: 97630840500 / 25
|
|
|
|
? |
504 749 98
|
Shaft seal |
1 |
InternBDB: BABSL 90x110x7,5 Viton 667 447 | InternKon: 97630840500 / 21
|
|
|
|
? |
504 748 98
|
O-ring |
1 |
InternBDB: 230x5 Viton 80Sh | InternKon: 97630840500 / 22
|
|
|
|
? |
754 495
|
Sealing flange |
1 |
InternBDB: 602 175 | InternKon: 97630840500 / 11
|
|
|
|
? |
754 496
|
Circlip |
1 |
InternBDB: 240x5 SO /Geschl. 127 698 | InternKon: 97630840500 / 24
|
|
|
|
? |
754 497
|
Repair kit
fig-nos. 05,35,36,37 |
-2 |
InternBDB: E-ST
|
|
|
|
? |
973 125
|
Fluid sealing 50 ml
to fig-no. 20 |
-2 |
InternBDB: Loctite 241
|
|
|
|
? |
989 946
|
Fluid sealing 50 ml
(pipe thread) |
-2 |
InternBDB: Loctite 572
|
|
