PC400LC-6 S/N 30001-UP (SAA6D125E-2 (Emission) Eng. Installed)

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Options
?	208-944-0201	SHORT ARM ASS'Y	1	SN: 32994-UP
?	208-944-0200	SHORT ARM ASS'Y	1	SN: 30001-32993
?		ARM	1	SN: 33026-UP
?		ARM	1	SN: 30001-33025
?	208-70-61521	BUSHING	2	SN: 30001-UP
?	208-70-13141	BUSHING	2	SN: 30001-UP
?	208-70-72170	BUSHING	2	SN: 32994-UP
?	208-70-32140	BUSHING	2	SN: 30001-32993
?	07020-00000	FITTING	2	SN: 30001-UP
?	07145-00120	SEAL	2	SN: 30001-UP
?	208-70-12231	SEAL,DUST	2	SN: 30001-UP
?	205-70-62160	SEAL	2	SN: 30001-UP
?	208-70-61220	PIN	1	SN: 30001-UP
?	205-70-66580	PLATE	1	SN: 30001-UP
?	01010-81235	BOLT	2	SN: 30001-UP
?	01643-31232	WASHER	2	SN: 30001-UP
?	208-70-61240	PIN	1	SN: 30001-UP
?	205-70-66580	PLATE	1	SN: 30001-UP
?	01010-81235	BOLT	2	SN: 30001-UP
?	01643-31232	WASHER	2	SN: 30001-UP
?	207-70-11340	SPACER, 0.8MM	3	SN: 30001-UP
?	208-63-X9040	CYLINDER GROUP,(SEE FIG.Y1620-41A0A)	1	SN: 32339-UP
?	208-63-X2531	BUCKET CYLINDER G.,(SEE FIG.Y1620-41A0A)	1	SN: 32001-32338
?	208-63-X2130	BUCKET CYLINDER G.,(SEE FIG.Y1620-41A0)	1	SN: 30001-31999

Komatsu PC400LC-6 S/N 30001-UP (SAA6D125E-2 (Emission) Eng. Installed) parts catalog PDF

ARM (2.9M) (ARM AND BUCKET CYLINDER) (T1200-01B3) in PC400LC-6 S/N 30001-UP (SAA6D125E-2 (Emission) Eng. Installed). Diagram image and parts list.
