324 830 40
|
Travelling gear assy. |
1 |
InternBDB: L & S GFT 130F 1005 AT-Nr. 669 110 73
|
|
|
|
? |
505 768 98
|
Bolt |
12 |
InternBDB: M16x50 /931 | InternKon: 4/6099/3005/0 / 38
|
|
|
|
? |
313 397 99
|
Plug |
2 |
InternBDB: M18x1,5 /908 | InternKon: 4/6099/3005/0 / 42
|
|
|
|
? |
339 897 99
|
Seal |
2 |
InternBDB: A18x22 /7603 | InternKon: 4/6099/3005/0 / 43
|
|
|
|
? |
804 362 73
|
Cover |
1 |
InternBDB: 0/0438/9421/0 | InternKon: 4/6099/3005/0 / 18
|
|
|
|
? |
804 363 73
|
Cylindrical roller |
1 |
InternBDB: LF 935 566 | InternKon: 4/6099/3005/0 / 17
|
|
|
|
? |
804 364 73
|
Ring gear |
1 |
InternBDB: 2/0334/9048/0 | InternKon: 4/6099/3005/0 / 4
|
|
|
|
? |
307 807 99
|
Bolt |
12 |
InternBDB: M12x45 /933 | InternKon: 4/6099/3005/0 / 39
|
|
|
|
? |
804 365 73
|
Drive shaft |
1 |
InternBDB: 2/0255/9575/0 | InternKon: 4/6099/3005/0 / 81
|
|
|
|
? |
804 587 73
|
O-ring 1,75mm
Bulk ware, state length
required |
2 |
InternBDB: Ш 4x1,75 mm | InternKon: 4/6099/3005/0 / 34
|
|
|
|
? |
989 965
|
Adhesive to fig-no. 10 |
1 |
InternBDB: Sico-Met 85
|
|
|
|
? |
804 366 73
|
Planetary carrier assy. |
1 |
InternBDB: 6/6099/2601/ T 83 | InternKon: 4/6099/3005/0 / 83
|
|
|
|
? |
804 367 73
|
Sun gear |
1 |
InternBDB: 3/0255/9579/0 | InternKon: 4/6099/3005/0 / 5
|
|
|
|
? |
804 368 73
|
Planetary carrier assy. |
1 |
InternBDB: 6/6099/2503/ T 7 | InternKon: 4/6099/3005/0 / 7
|
|
|
|
? |
804 369 73
|
Sun gear |
1 |
InternBDB: 2/0255/9580/0 | InternKon: 4/6099/3005/0 / 6
|
|
|
|
? |
804 505 73
|
Stop washer |
1 |
InternBDB: 4/0409/9214/0 | InternKon: 4/6099/3005/0 / 15
|
|
|
|
? |
804 506 73
|
Planetary carrier assy. |
1 |
InternBDB: 6/6099/2503/ T 8 | InternKon: 4/6099/3005/0 / 8
|
|
|
|
? |
804 371 73
|
Ring gear |
1 |
InternBDB: 0/0334/9047/0 | InternKon: 4/6099/3005/0 / 1
|
|
|
|
? |
804 507 73
|
Shaft nut |
1 |
InternBDB: 3/0414/9023/1 | InternKon: 4/6099/3005/0 / 14
|
|
|
|
? |
973 412 73
|
Roller bearing |
1 |
InternBDB: LM 545 849 | InternKon: 4/6099/3005/0 / 22
|
|
|
|
? |
804 508 73
|
Support ring |
1 |
InternBDB: 0/0406/9541/0 | InternKon: 4/6099/3005/0 / 3
|
|
|
|
? |
973 413 73
|
Roller bearing |
1 |
InternBDB: 96900 | InternKon: 4/6099/3005/0 / 23
|
|
|
|
? |
320 222 99
|
Bolt |
24 |
InternBDB: M27x80 /912 10.9 | InternKon: 4/6099/3005/0 / 41
|
|
|
|
? |
255 058 40
|
Lifetime seal |
1 |
InternBDB: Gцtze 76.90 H-27 | InternKon: 4/6099/3005/0 / 35
|
|
|
|
? |
804 509 73
|
Axle |
1 |
InternBDB: 0/0309/9226/1 | InternKon: 4/6099/3005/0 / 50
|
|
|
|
? |
360 511 99
|
Ball bearing |
1 |
InternBDB: 6011 /625 | InternKon: 4/6099/3005/0 / 19
|
|
|
|
? |
804 377 73
|
Cam |
1 |
InternBDB: 3/0343/9415/0 | InternKon: 4/6099/3005/0 / 51
|
|
|
|
? |
180 749 40
|
O-ring |
1 |
InternBDB: 192x4 | InternKon: 4/6099/3005/0 / 45
|
|
|
|
? |
313 395 99
|
Plug |
1 |
InternBDB: M12x1,5 /908 | InternKon: 4/6099/3005/0 / 120
|
|
|
|
? |
339 879 99
|
Seal |
1 |
InternBDB: A12x18 /7603 | InternKon: 4/6099/3005/0 / 121
|
|
|
|
? |
973 416 73
|
Outer race to fig-no: 19 |
1 |
InternBDB: LM 545 810 | InternKon: 4/6099/3005/0 / 22
|
|
|
|
? |
973 417 73
|
Outer race to fig-no: 21 |
1 |
InternBDB: 96140 | InternKon: 4/6099/3005/0 / 23
|
|
|
|
? |
342 577 99
|
Circlip |
1 |
InternBDB: 135x4 /471 | InternKon: 4/6099/3005/0 / 40
|
|
|
|
? |
973 164
|
Fluid sealing for fixing
of fig-nos: 06,08,15 |
-2 |
InternBDB: Loctite 270
|
|
