427 100 40
|
Fan supporting assy. |
1 |
|
|
|
|
? |
409 970 40
|
V-belt pulley |
1 |
InternKon: 427 100 40 / 3
|
|
|
|
? |
350 568 99
|
Grease nipple |
1 |
InternBDB: CM10x1/71412 | InternKon: 427 100 40 / 16
|
|
|
|
? |
342 668 99
|
Circlip |
1 |
InternBDB: 90x3/472 | InternKon: 427 100 40 / 28
|
|
|
|
? |
409 971 40
|
Distance bush |
1 |
InternKon: 427 100 40 / 9
|
|
|
|
? |
409 972 40
|
Shaft |
1 |
InternKon: 427 100 40 / 5
|
|
|
|
? |
354 493 99
|
Feather key |
1 |
InternBDB: 14x9x35/6885 | InternKon: 427 100 40 / 15
|
|
|
|
? |
501 601 98
|
Roller bearing |
2 |
InternBDB: 6210/625 RS | InternKon: 427 100 40 / 12
|
|
|
|
? |
319 265 99
|
Bolt |
6 |
InternBDB: M10x100/912 | InternKon: 427 100 40 / 26
|
|
|
|
? |
316 216 99
|
Washer |
2 |
InternBDB: 13/6916 | InternKon: 427 100 40 / 27
|
|
|
|
? |
424 917 40
|
V-belt pulley |
1 |
InternKon: 427 100 40 / 4
|
|
|
|
? |
427 188 40
|
Disk |
1 |
InternKon: 427 100 40 / 18
|
|
|
|
? |
350 569 99
|
Grease nipple |
1 |
InternBDB: CM6/71412 | InternKon: 427 100 40 / 17
|
|
|
|
? |
424 918 40
|
Distance bush |
1 |
InternKon: 427 100 40 / 14
|
|
|
|
? |
409 973 40
|
Spindle |
1 |
InternKon: 427 100 40 / 6
|
|
|
|
? |
409 974 40
|
Distance bush |
1 |
InternKon: 427 100 40 / 10
|
|
|
|
? |
342 651 99
|
Circlip |
2 |
InternBDB: 52x2 /472 | InternKon: 427 100 40 / 29
|
|
|
|
? |
427 130 40
|
Fan supporting |
1 |
InternKon: 427 100 40 / 1
|
|
|
|
? |
368 404 99
|
Roller bearing |
2 |
InternBDB: 6304-Z/625 | InternKon: 427 100 40 / 13
|
|
|
|
? |
424 916 40
|
Set screw |
1 |
InternBDB: TL/931 M10x140/8.8 | InternKon: 427 100 40 / 22
|
|
|
|
? |
427 253 40
|
Angle |
1 |
InternKon: 427 100 40 / 7
|
|
|
|
? |
427 254 40
|
Supporting surface |
1 |
InternKon: 427 100 40 / 11
|
|
|
|
? |
307 804 99
|
Bolt |
6 |
InternBDB: M12x30/933 | InternKon: 427 100 40 / 24
|
|
|
|
? |
333 116 99
|
Nut |
2 |
InternBDB: 16 /936 | InternKon: 427 100 40 / 32
|
|
|
|
? |
409 969 40
|
Intermediate disk |
1 |
InternKon: 427 100 40 / 8
|
|
|
|
? |
316 211 99
|
Washer |
3 |
InternBDB: 17 /6916
|
|
|
|
? |
427 249 40
|
Guide |
1 |
InternKon: 427 100 40 / 2
|
|
|
|
? |
409 978 40
|
Locking plate |
3 |
InternKon: 427 100 40 / 19
|
|
|
|
? |
332 113 99
|
Nut |
1 |
InternBDB: M10/934 | InternKon: 427 100 40 / 33
|
|
|
|
? |
414 236 40
|
Fan |
1 |
InternBDB: Cummins FN 4003 | InternKon: 427 100 40 / 21
|
|
|
|
? |
343 112 99
|
Lock washer |
2 |
InternBDB: 12 /128 | InternKon: 427 100 40 / 31
|
|
|
|
? |
307 869 99
|
Bolt |
6 |
InternBDB: M12x35 /933 | InternKon: 427 100 40 / 25
|
|
|
|
? |
316 211 99
|
Washer |
1 |
InternBDB: 17 /6916 | InternKon: 427 100 40 / 34
|
|
|
|
? |
308 639 99
|
Bolt |
3 |
InternBDB: M16x110 /931 | InternKon: 409 990 40 / 66
|
|
|
|
? |
030 176 99
|
V-belt set |
1 |
InternBDB: 4x12,5x1268 / 7753 | InternKon: 409 990 40 / 61
|
|
