01 |
|
Electric pump |
1 |
InternKon: 651 683 40 / 1
|
991-0094 |
|
|
02 |
|
Pinion installation |
1 |
InternBDB: 619 900 40
|
086-2395 |
|
|
03 |
|
Lube pump arr. |
1 |
|
116-2312b |
|
|
04 |
|
Grease |
-2 |
|
090-0973a |
|
|
05 |
007 138 98
|
Union |
2 |
InternBDB: Voss 6-LR | InternKon: 651 683 40 / 7
|
|
|
|
06 |
515 028 40
|
Collet |
4 |
InternBDB: 432-23031-1 | InternKon: 651 683 40 / 6
|
|
|
|
07 |
515 029 40
|
Hose connection 90 ? |
4 |
InternBDB: 532-30739-1 | InternKon: 651 683 40 / 5
|
|
|
|
08 |
576 160 40
|
Plastic hose DN 4
Bulk ware, state length required |
-2 |
InternKon: 651 683 40 / 4
|
|
|
|
09 |
358 286 40
|
Diaphragm type pressure switch |
1 |
InternBDB: Suco 7032-3 5 bar | InternKon: 651 683 40 / 12
|
|
|
|
10 |
323 952 40
|
Protection cap |
1 |
InternBDB: 1-1-53621-001 | InternKon: 651 683 40 / 13
|
|
|
|
11 |
372 870 99
|
Union |
1 |
InternBDB: MAV 12-LR | InternKon: 651 683 40 / 11
|
|
|
|
12 |
215 424 99
|
Pipe Ш 12
Bulk ware, state length required |
-2 |
InternKon: 651 683 40 / 10
|
|
|
|
13 |
343 873 40
|
Shuttle valve |
1 |
InternBDB: 12-L | InternKon: 651 683 40 / 9
|
|
|
|
14 |
371 953 99
|
Union |
2 |
InternBDB: FFL 12 /2353
|
|
|
|
15 |
356 184 40
|
Relay |
1 |
InternKon: 462 593 40 / 2
|
|
|
|
16 |
323 310 40
|
Socket |
1 |
InternKon: 462 593 40 / 3
|
|
|
|
17 |
323 311 40
|
Spring retainer |
1 |
InternKon: 462 593 40 / 4
|
|
|
|
18 |
324 400 40
|
Turn switch |
1 |
InternBDB: Merit 261 000
|
|
|
|
19 |
385 209 40
|
Indicator light |
1 |
InternBDB: 51.050.002
|
|
|
|
20 |
356 156 40
|
Bulb |
1 |
InternBDB: 31-963-28
|
|
|
|
21 |
385 210 40
|
Push hood, red |
1 |
InternBDB: 51-955.2
|
|
|
|
22 |
500 280 98
|
Socket |
2 |
InternBDB: RI 3/8 x 1/8 | InternKon: 651 683 40 / 2
|
|
|
|
23 |
372 446 99
|
Union |
2 |
InternBDB: DL 6 /2353 | InternKon: 651 683 40 / 3
|
|
|
|
24 |
461 377 40
|
Cycle relay |
1 |
InternBDB: ZR 06 4290 | InternKon: 462 593 40 / 1
|
|
