H135S S/N 61064

Komatsu parts book diagram for H135S S/N 61064: LUBE DISTRIBUTOR, PROGRESS. OPERATING

01 02 03 04 05 06 07 08 09 09 09 09 09 10 10 10 10 10 10 10 10 11 11 11 11 11 12 12 12 12 12 13 13 13 13 13 13 14 14 14 14 14 14 15 15 15 15 15 15 15 16 16 16 16 16 17 17 17 17 17 18 18 18 18 18 19 19 19 19 19

	#	Part Number	Partname	Quantity	Options	Reference
	01	698 071 73	Lube distrib., progress. operat. 3/6	1	InternBDB: MX-F 3/6 /4010.035.44.0003
	02	698 068 73	Lube distrib., progress. operat. 4/8	1	InternBDB: MX-F 4/8 /4010.045.44.0003
	03	698 069 73	Lube distrib., progress. operat. 5/10	1	InternBDB: MX-F 5/10 /4010.055.44.0003
	04	698 070 73	Lube distrib., progress. operat. 6/12	1	InternBDB: MX-F 6/12 /4010.065.44.0003
	05	698 127 73	Lube distrib., progress. operat. 7/14	1	InternBDB: MX-F 7/14 /4010.075.44.0003
	06	764 922 73	Lube distrib., progress. operat. 8/16	1	InternBDB: MX-F 8/16 /4010.085.44.0003
	07	764 955 73	Lube distrib., progress. operat. 9/18	1	InternBDB: MX-F 9/18 /4010.095.44.0003
	08	698 124 73	Lube distrib., progress. operat. 10/20	1	InternBDB: MX-F 10/20 /4010.105.44.0003
	09	764 566 73	Initial element 75	-2	InternBDB: 4010.94.001
	10	764 567 73	Center element 75	-2	InternBDB: 4010.95.103 MX-F 75
	11	764 570 73	Final element 75	-2	InternBDB: 4010.96.103
	12	764 000 73	Union	-2
	13	698 217 73	Union	-2	InternBDB: 1002.01.010
	14	764 007 73	Taper ring	-2
	15	764 006 73	Plug	-2	InternBDB: 4010.96.005.0000
	16	511 824 98	O-ring	-2	InternBDB: 2x1,5 /3771 NBR 90 SH
	17	511 825 98	O-ring	-2	InternBDB: 7,5x1,5 /3771 NBR 90 SH
	18	511 826 98	O-ring	-2	InternBDB: 11,5x1,5 /3771 NBR 90 SH
	19	500 274 98	O-ring	-2	InternBDB: 6x1,5 /3771 NBR 90 SH

Komatsu H135S S/N 61064 parts catalog PDF

LUBE DISTRIBUTOR, PROGRESS. OPERATING (090-2385) in H135S S/N 61064. Diagram image and parts list.
