H6100-01A0 HYDRAULIC PUMP | WB156-5 BACKHOE LOADER S/N A63001-UP

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity	Options	Reference
?	708-1U-00111	PUMP, HYDRAULIC	1
?		OR	-1
?	708-1U-00112	PUMP, HYDRAULIC	1
?		HOUSINGS (SEE FIG. H6101-01A0 )	-1	SN: A63001-A63103-UP	H6101-01A0
?		ROTATING BLOCK (SEE FIG. H6102-01A0 )	-1	SN: A63001-A63103-UP	H6102-01A0
?		CONTROL VALVE (SEE FIG. H6103-01A0 )	-1	SN: A63001-A63103-UP	H6103-01A0
?		VALVE MOUNTING (SEE FIG. H6104-01A0 )	-1	SN: A63001-A63103-UP	H6104-01A0
?		OR	-1
?	708-1U-00160	PUMP, HYDRAULIC	1
?		HOUSINGS (SEE FIG. H6105-01A0 )	-1	SN: A63104--UP	H6105-01A0
?		ROTATING BLOCK (SEE FIG. H6105-02A0 )	-1	SN: A63104--UP	H6105-02A0
?		CONTROL VALVE (SEE FIG. H6105-03A0 )	-1	SN: A63104--UP	H6105-03A0
?		VALVE MOUNTING (SEE FIG. H6105-04A0 )	-1	SN: A63104--UP	H6105-04A0
?		BLOCK (SEE FIG. H6105-05A0 )	-1	SN: A63104--UP	H6105-05A0
?	01016-51645	BOLT	2	SN: A63001--UP
?	01643-31645	WASHER	2	SN: A63001--UP
?	42N-60-11330	GASKET KIT	1	SN: A63001--UP
?			-1
?		F1 - WB146-5 S/N A23001 - A24160 WB146PS-5 S/N A43001 - A43033 WB156-5 S/N A63001 - A63065 WB156PS-5 S/N A73001 - A73028	-1
?			-1
?		F2 - WB146-5 S/N A24161 - A24597 WB146PS-5 S/N A43034 - A43054 WB156-5 S/N A63066 - A63103 WB156PS-5 S/N A73029 - A73056	-1
?			-1
?		F3 - WB146-5 S/N A24598 AND UP WB146PS-5 S/N A43055 AND UP WB156-5 S/N A63104 AND UP WB156PS-5 S/N A73057 AND UP	-1
?			-1
?		F4 - WHEN REPLACING OLD HYDRAULIC PUMP, PUR CHASE NEW PUMP P/N 708-1U-00160. IT IS ALSO RECOMMENDED TO UPDATE THE HYDRAULIC TANK ASSEMBLY TO 42N-60-11502 WHEN INSTALLING HYDRAULIC PUMP 708-1U-00160.	-1
