WB140PS-2N S/N A40034-UP

Komatsu parts book diagram for WB140PS-2N S/N A40034-UP: FIG. F3300-01A0 TRANSMISSION - COMPLETE ASSEMBLY

2 4 3 1

	#	Part Number	Partname	Quantity	Options	Reference
	1	200120067	TRANSMISSION	1	SN: A40034-A40052-UP
	\|$1		OIL FILTER (SEE FIG. F3300-01A1)	-1	SN: A40034-A40052-UP	F3300-01A1
	\|$2		HOUSINGS (SEE FIG. F3300-01A1)	-1	SN: A40034-A40052-UP	F3300-01A1
	\|$3		F & R CLUTCH (SEE FIG. F3300-01A2)	-1	SN: A40034-A40052-UP	F3300-01A2
	\|$4		REV IDLER SHAFT (SEE FIG. F3300-01A3)	-1	SN: A40034-A40052-UP	F3300-01A3
	\|$5		2ND GEAR CLUTCH (SEE FIG. F3300-01A3)	-1	SN: A40034-A40052-UP	F3300-01A3
	\|$6		1 3 & 4 CLUTCHES (SEE FIG. F3300-01A4)	-1	SN: A40034-A40052-UP	F3300-01A4
	\|$7		FRONT OUTPUT SHAFT (SEE FIG. F3300-01A5)	-1	SN: A40034-A40052-UP	F3300-01A5
	\|$8		TRANS PUMP (SEE FIG. F3300-01A6)	-1	SN: A40034-A40052-UP	F3300-01A6
	\|$9		TORQUE CONVERTER (SEE FIG. F3300-01A7)	-1	SN: A40034-A40052-UP	F3300-01A7
	\|$10		SHIFT SYSTEM (SEE FIG. F3300-01A8)	-1	SN: A40034-A40052-UP	F3300-01A8
	\|$11		TUBING SENSORS (SEE FIG. F3300-01A9)	-1	SN: A40034-A40052-UP	F3300-01A9
	1	200120077	TRANSMISSION	1
	2	YM261060-80252	BOLT	8
	3	YM121850-21130	BOLT	6
	4	YM123910-21500	HUB, INTERMEDIATE	1
	\|$16			-1
	\|$17		F1 REFER TO PSN AA04165 FOR ADDITIONAL S/N BREAKS. FOR COMPLETETRANSMISSION REPLACEMENT, ORDERS THE FOLLOWING PARTS:	-1
	\|$18			-1

Komatsu WB140PS-2N S/N A40034-UP parts catalog PDF

FIG. F3300-01A0 TRANSMISSION - COMPLETE ASSEMBLY (F3300-01A0) in WB140PS-2N S/N A40034-UP. Diagram image and parts list.
