FIG. A0150-01A0 ENGINE - ALTERNATOR MOUNTING | WB140PS-2N S/N A40034-UP

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity	Options	Reference
\|$0		ENGINE, TIER I (SEE FIG. A0100-01A0)	-1	SN: A40034-A40042-UP	A0100-01A0
\|$1		ENGINE, TIER II (SEE FIG. A0100-01A1)	-1	SN: A40043--UP	A0100-01A1
1		ALTERNATOR, 80A (SEE FIG. A0150-01A1)	-1	SN: A40034--UP	A0150-01A1
2	YM123900-77340	SPACER	1	SN: A40034--UP
3	YM221371-00000	WASHER	1	SN: A40034--UP
4	YM261161-01202	BOLT	1	SN: A40034--UP
5	YM263661-00002	NUT	1	SN: A40034--UP
6	YM123900-77330	BRACKET	1	SN: A40034--UP
7	YM121236-77340	SPACER	1	SN: A40043--UP
8	YM119810-77340	BOLT	1	SN: A40034-A40042-UP
8	YM119005-77350	BOLT	1	SN: A40043--UP
9	YM260140-80252	BOLT	1	SN: A40034--UP
10		THERMOSTAT (SEE FIG. A0141-01A0)	-1	SN: A40034-A40042-UP	A0141-01A0
10		THERMOSTAT (SEE FIG. A0141-01A1)	-1	SN: A40043--UP	A0141-01A1
11		GEAR CASE (SEE FIG. A0111-01A0)	-1	SN: A40034-A40042-UP	A0111-01A0
11		GEAR CASE (SEE FIG. A0111-01A1)	-1	SN: A40043--UP	A0111-01A1
\|$16		RELAY, TIMER (SEE FIG. E1500-01A4)	-1	SN: A40034-A40042-UP	E1500-01A4
\|$17		RELAY, TIMER (SEE FIG. E1500-01B4)	-1	SN: A40043--UP	E1500-01B4
\|$18		RELAY, TIMER (SEE FIG. E1500-01A4)	-1	SN: A40034-A40042-UP	E1500-01A4
\|$19		RELAY, TIMER (SEE FIG. E1500-01B4)	-1	SN: A40043--UP	E1500-01B4
\|$20		RELAY, TIMER (SEE FIG. E1500-01A4)	-1	SN: A40034-A40042-UP	E1500-01A4
\|$21		RELAY, TIMER (SEE FIG. E1500-01B4)	-1	SN: A40043--UP	E1500-01B4
\|$22			-1
\|$24			-1
