AFE73-V 980E-4 S/N A40166 - A40172 BUENAVISTA

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	XA4256	SENSOR, SPEED (1)	1
?	GE0628	CAPSCREW - 5/16" - 18NC X 2 1/4"	2
?	58E-00-01570	FLAT WASHER - 5/16"	2
?	XA4257	THREADLOCK	-1
?	VE4515	FLAT WASHER - 3/8"	14
?	VE4641	CAPSCREW - 3/8" - 16NC X 1 1/4"	3
?	GE1475	CLAMP	1
?	58F-06-41900	BLOCK	-1
?	VE7206	TAPE, FIBERGLASS	-1
?	VE4640	CAPSCREW - 3/8" - 16NC X 1 1/2" (1)	4
?	VE4701	CAPSCREW - 3/8" - 16NC X 3"	2
?	XA4324	STRAP, CONNECTION	3
?	VE4747	NUT	5
?	VE4687	LOCKWASHER - 3/8"	5
?	GE1476	SLEEVE, SHAFT	1
?	GE1366	PIPE, SUPPORT (2)	2
?	58F-33-00090	ADAPTER, PARKING BRAKE	1
?	58B-06-50150	CAPSCREW - 3/4" X 10NC X 5 1/2" (1)/(2)	2
?	58B-06-02170	RETAINER, PARKING BRAKE	1
?	58B-06-02160	CAPSCREW - 1 1/4" X 7NC X 2 3/4"	1
?	GE0449	FLAT WASHER - 1 1/4"	1
?	58B-WM-AK100	NOTE: (1) INCLUDED IN 58B-WM-AK100 TRACTION MOTOR KIT.	-1
?		(2) USED FOR SHIPPING AND STORAGE ONLY.	-1

Komatsu AFE73-V 980E-4 S/N A40166 - A40172 BUENAVISTA parts catalog PDF

ELECTRIC WHEEL MOTOR 3/3 58B-06-10372 (62560) in AFE73-V 980E-4 S/N A40166 - A40172 BUENAVISTA. Diagram image and parts list.
