Diagram image 1 of 2

PC3000-6 S/N 06382

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

PC3000-6 S/N 06382

#	Part Number	Partname	Quantity	Reference
?		Metering valve	10	991-0323a
?		Metering valve	1	991-0091
?		Metering valve	1	991-0091
?	654 130 40	Protection cap	6
?	308 555 99	Bolt	3
?	517 121 98	Lock washer	3
?	906 981 40	Union	6
?	512 273 98	Socket	1
?	906 984 40	Union	2
?	518 355 98	Hose assy.	1
?	634 481 40	Union	1
?	516 834 98	Union	1
?	374 443 99	Union	1
?	371 271 99	Union nut	12
?	907 080 40	Olive	30
?	515 028 40	Collet	28
?	515 029 40	Hose connection	12
?	936 979 40	Thread plate	1
?	936 978 40	Thread plate	1
?	371 257 99	Union nut	16
?	515 027 40	Hose connection	16
?	371 264 99	Union nut	4
?	906 868 40	Olive	5
?	371 260 99	Union nut	5
?	906 351 40	Olive	5
?	517 122 98	Lock washer	6
?	308 579 99	Bolt	6
?	517 291 98	Union	12
?	374 428 99	Union	4
?	576 160 40	Hose DN 4	-2
?	655 649 40	Cable protection hose DN 10	-2
?	0443551210	Double-Clamp 2xШ12	24
?	0443451210	Clamp Ш12	19
?	340 111 99	Washer	43
?	907 854 40	Thread pin	43
?	340 465 99	Washer	43
?	502 618 98	Clamp set	3
?	534 005 99	Weld on plate	3
?	534 004 99	Cover plate	3
?	504 926 98	Grommet	3
?	308 582 99	Bolt	2
?	517 122 98	Lock washer	6
?	929 431 40	Clamp	4
?	634 978 40	Cover plate	8
?	512 055 98	Thread pin	8
?	334 600 99	Nut	37
?	936 962 40	Pipe	1
?	942 852 40	Pipe	1
?	942 826 40	Pipe	1
?	951 351 40	Hose assy. with synthetic helix	2
?	516 678 98	Hose assy. DN 20x5500	1
?	942 824 40	Angle	4
?	957 650 40	Protection plate	1
?	634 271 40	Union	1
?	504 224 98	Clamp set	6
?	0443453412	Clamp Ш34	1
?	507 121 98	Thread pin	1
?	340 467 99	Washer	2
?	931 897 40	Guard plate	1
?	534 001 99	Cover plate	4
?	534 002 99	Weld on plate	3
?	909 206 40	Cover tube	2
?	307 805 99	Bolt	4
?	517 118 98	Lock washer	12
?	511 773 98	Thread pin	2
?	507 037 98	Nut	43
?	324 672 40	Plug	1
?	0443451510	Clamp Ш15	1
?	907 378 40	Swivel union	1
?	517 561 98	Union	1
?	374 442 99	Union	3
?	957 659 40	Lubrication pipe protection, left	1
?	957 661 40	Lubrication pipe protection, right	1
?	957 653 40	Thread plug	8
?	307 824 99	Bolt	8
?	517 123 98	Lock washer	12
?	931 891 40	Upper Plate	1
?	923 389 40	Lower Plate	1
?	957 639 40	Thread pin	4
?	931 895 40	Pipe	1
?	502 303 98	Socket	6
?	517 148 98	Socket	1
?	654 496 40	Protection cap	10
?	957 640 40	Covering Plate	1
?	655 268 40	Union	4
?	907 151 40	Olive	12
?	371 263 99	Union nut	12
?	517 255 98	Union	1
?	950 511 40	Half clamp	24
?	634 774 40	Cover plate	12
?	907 341 40	Straight swivel union	1
?	516 700 98	Union	1
?	942 851 40	Weld on plate	1
?	652 383 40	Shackle	2
?	428 861 40	Pipe assy. Ш 16	2
?	942 823 40	Lower Plate	1
?	308 612 99	Bolt	24
?	509 308 98	Locking plate	2
?	308 611 99	Bolt	8
?	516 183 98	Socket	1
?	516 173 98	Socket	1
?	551 615 40	Union	1
?	371 861 99	Breech block	1
?	551 456 40	Union	1
?	634 546 40	Union	1
?	517 560 98	Union	10
?	307 830 99	Bolt	4
?	341 754 40	Ultimate pressure control	1

Komatsu PC3000-6 S/N 06382 parts catalog PDF

CENTRAL LUBRICATION - STICK BH 4.0 M (485-2372k) in PC3000-6 S/N 06382. Diagram image and parts list.
