AFE77-BL 830E-5 S/N A50167 - A50168 CONUMA COAL

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Reference
?	VC4898	CAPSCREW - 1/2" - 13NC X 2 1/2"	2
?	TL8151	JAM NUT - 1/2" - 20NF	4
?	PC1247	ROD END, FEMALE	4
?	EK1726	ROD, THREADED	1
?	DF3500	LOCKNUT - 1/2" - 13NC	4
?	WA4728	FLAT WASHER, HARDENED - 1/2"	8
?	WA0471	CAPSCREW - 1/2" - 13NC X 2 1/4"	2
?	EJ9909	CLAMP	2
?	WB1177	CLAMP, T-BOLT	4
?	VW7882	HOSE	1
?	VC1390	LOCKWASHER - 5/8"	13
?	58F-09-00450	CAPSCREW - 5/8" - 11NC X 4 1/2"	13
?	WA4729	FLAT WASHER, HARDENED - 5/8"	13
?	58E-54-30540	BRACKET	1
?	MM0714	FLAT WASHER, HARDENED - M12	4
?	MM0616	CAPSCREW - M12 X 1.75 X 20	4
?	58F-02-00160	AIR CLEANER ASSEMBLY, DUAL (SEE INDEX)	1	43406
?	TX6040	ELBOW, RUBBER - 45 DEG	1
?	WB1179	CLAMP, T-BOLT	4
?	58F-02-51490	BRACKET	1
?	EJ9917	ROD, THREADED	1
?	TB1019	RAIN GUARD, SIDE	1
?	58E-02-00600	TUBE, AIR INTAKE - LH OUTER FRONT	1
?	TB1018	RAIN GUARD, SIDE	1
?	58E-02-00800	TUBE, AIR INTAKE - LH INNER FRONT	1

Komatsu AFE77-BL 830E-5 S/N A50167 - A50168 CONUMA COAL parts catalog PDF

AIR CLEANER PIPING & INSTALLATION - LH 2/2 (65208) in AFE77-BL 830E-5 S/N A50167 - A50168 CONUMA COAL. Diagram image and parts list.
