AFE77-BL 830E-5 S/N A50167 - A50168 CONUMA COAL

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	EJ9909	CLAMP	5
?	WA4728	FLAT WASHER, HARDENED - 1/2"	24
?	DF3500	LOCKNUT - 1/2" - 13NC	12
?	WA0471	CAPSCREW - 1/2" - 13NC X 2 1/4"	3
?	VC4898	CAPSCREW - 1/2" - 13NC X 2 1/2"	6
?	TL8151	JAM NUT - 1/2" - 20NF	12
?	PC1247	ROD END, FEMALE	12
?	EK4005	ROD, THREADED	1
?	VC6500	CAPSCREW - 1/2" - 13NC X 2"	3
?	EG7576	CLAMP, DOUBLE	2
?	PC1115	HOSE, DOUBLE HUMP	2
?	EK5667	ROD, THREADED	1
?	EJ9914	ROD, THREADED	1
?	58E-02-50041	TUBE, INTAKE	1
?	WB1170	CLAMP, T-BOLT	4
?	PC0858	ELBOW, REDUCING - 90 DEG	2
?	WB1169	CLAMP, T-BOLT	2
?	EL2146	ROD, THREADED	1
?	58E-02-50070	TUBE, INTAKE	1
?	EM4603	ROD, THREADED	1
?	58E-02-50351	ROD, THREADED	1
?	58E-54-52071	BRACKET	1
?	MM0461	FLAT WASHER - M10	2
?	MM0471	LOCKWASHER - M10	2
?	MM0607	CAPSCREW - M10 X 1.50 X 35	2
?	58E-02-50100	CLAMP - 6"	1
?	C5768	PLUG, PIPE - 1/8"	1

Komatsu AFE77-BL 830E-5 S/N A50167 - A50168 CONUMA COAL parts catalog PDF

AIR CLEANER PIPING & INSTALLATION - RH 1/2 (65210) in AFE77-BL 830E-5 S/N A50167 - A50168 CONUMA COAL. Diagram image and parts list.
