Diagram image 1 of 2

PC4000-11 S/N 08312

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

PC4000-11 S/N 08312

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Options	Reference
?	98528740	EMERGENCY LADDER	1	vendorcode: KOMATSU \| visiblepartno: 98528740
?	98528840	LADDER	1	vendorcode: KOMATSU \| visiblepartno: 98528840
?	10244042	LADDER	1	vendorcode: KOMATSU \| visiblepartno: 10244042
?	97218540	RETAINER FOR ROLLE	1	vendorcode: KOMATSU \| visiblepartno: 97218540
?	97219940	ROLLER	1	vendorcode: KOMATSU \| visiblepartno: 97219940
?	97217540	LEVER CARRIER	1	vendorcode: KOMATSU \| visiblepartno: 97217540
?	97218040	LEVER	1	vendorcode: KOMATSU \| visiblepartno: 97218040
?	97219540	CATCH LEVER	1	vendorcode: KOMATSU \| visiblepartno: 97219540
?	97684940	PLATE	4	vendorcode: KOMATSU \| visiblepartno: 97684940
?	10650142	SLIDING PAD	2	vendorcode: KOMATSU \| visiblepartno: 10650142
?	97684740	SLIDING PAD	1	vendorcode: KOMATSU \| visiblepartno: 97684740
?	97684840	PLATE	4	vendorcode: KOMATSU \| visiblepartno: 97684840
?	97684540	SLIDING PAD	2	vendorcode: KOMATSU \| visiblepartno: 97684540
?	97685140	PLATE	1	vendorcode: KOMATSU \| visiblepartno: 97685140
?	98477040	PLATE	2	vendorcode: KOMATSU \| visiblepartno: 98477040
?	97685340	RING	2	vendorcode: KOMATSU \| visiblepartno: 97685340
?	98477140	SLIDING PAD	2	vendorcode: KOMATSU \| visiblepartno: 98477140
?	97685940	PIN	1	vendorcode: KOMATSU \| visiblepartno: 97685940
?	97686040	PIN	1	vendorcode: KOMATSU \| visiblepartno: 97686040
?	97685840	PIN	2	vendorcode: KOMATSU \| visiblepartno: 97685840
?		HYDR. CYLINDER WITH ACCUMULATOR	1	assembly: 535-1027B \| assemblytitle: HYDR. CYLINDER WITH ACCUMULATOR	535-1027B
?	51074498	ANTI-FATIGUE SLEEVE	6	vendorcode: KOMATSU \| visiblepartno: 51074498
?	30843799	BOLT	6	vendorcode: KOMATSU \| visiblepartno: 30843799
?	52017498	WASHER	22	vendorcode: KOMATSU \| visiblepartno: 52017498
?	33235399	NUT	16	vendorcode: KOMATSU \| visiblepartno: 33235399
?	52054198	WASHER	12	vendorcode: KOMATSU \| visiblepartno: 52054198
?	31914299	SCREW	6	vendorcode: KOMATSU \| visiblepartno: 31914299
?	33459999	NUT	6	vendorcode: KOMATSU \| visiblepartno: 33459999
?	52054598	WASHER	8	vendorcode: KOMATSU \| visiblepartno: 52054598
?	50200698	BOLT	8	vendorcode: KOMATSU \| visiblepartno: 50200698
?	30858399	BOLT	2	vendorcode: KOMATSU \| visiblepartno: 30858399
?	50703798	NUT	4	vendorcode: KOMATSU \| visiblepartno: 50703798
?	51279898	BOLT	2	vendorcode: KOMATSU \| visiblepartno: 51279898
?	51274898	NUT	4	vendorcode: KOMATSU \| visiblepartno: 51274898
?	97685540	COMPRESSION SPRING	2	vendorcode: KOMATSU \| visiblepartno: 97685540
?	89653540	RUBBER BUFFER	1	vendorcode: KOMATSU \| visiblepartno: 89653540
?	34046799	WASHER	1	vendorcode: KOMATSU \| visiblepartno: 34046799
?	51492298	NUT	1	vendorcode: KOMATSU \| visiblepartno: 51492298
?	97685440	DRAW SPRING	2	vendorcode: KOMATSU \| visiblepartno: 97685440
?	34208199	COTTER PIN	5	vendorcode: KOMATSU \| visiblepartno: 34208199
?	34210199	COTTER PIN	2	vendorcode: KOMATSU \| visiblepartno: 34210199
?	50158198	WASHER	2	vendorcode: KOMATSU \| visiblepartno: 50158198
?	34061399	WASHER	4	vendorcode: KOMATSU \| visiblepartno: 34061399
?	35056299	GREASE NIPPLE	4	vendorcode: KOMATSU \| visiblepartno: 35056299
?	51948898	PIN	1	vendorcode: KOMATSU \| visiblepartno: 51948898
?	34061299	WASHER	2	vendorcode: KOMATSU \| visiblepartno: 34061299
?	34205999	COTTER PIN	2	vendorcode: KOMATSU \| visiblepartno: 34205999
?	51948698	PIN	2	vendorcode: KOMATSU \| visiblepartno: 51948698
?	51948798	PIN	1	vendorcode: KOMATSU \| visiblepartno: 51948798
?	34060799	WASHER	1	vendorcode: KOMATSU \| visiblepartno: 34060799
?	51757398	ANTI-FATIGUE SLEEVE	4	vendorcode: KOMATSU \| visiblepartno: 51757398
?	30845999	BOLT	2	vendorcode: KOMATSU \| visiblepartno: 30845999
?	9895540	RING	2	vendorcode: KOMATSU \| visiblepartno: 9895540
?	47268899	CHAIN	-1	docwarecomment: * \| vendorcode: KOMATSU \| visiblepartno: 47268899
?	51952898	CLEVIS	1	vendorcode: KOMATSU \| visiblepartno: 51952898
?	30894799	BOLT	2	vendorcode: KOMATSU \| visiblepartno: 30894799
?	10650242	FILLER PLATE	1	vendorcode: KOMATSU \| visiblepartno: 10650242
?		BULK WARE, STATE LENGTH REQUIRED	-1	docwarecomment: *

Komatsu PC4000-11 S/N 08312 parts catalog PDF

EMERGENCY LADDER-CAB (360-1025B) in PC4000-11 S/N 08312. Diagram image and parts list.
