PC4000-11 S/N 08312

Komatsu parts book diagram for PC4000-11 S/N 08312: HYDRAULIC TENSIONER

01 02 03 04 04 04 05 05 06 07 08 09 10 10

	#	Part Number	Partname	Quantity	Options	Reference
	01	98491040	TENSIONER ASSY.	1	vendorcode: KOMATSU \| visiblepartno: 98491040
	01	10506542	TENSIONER ASSY.	1	vendorcode: KOMATSU \| visiblepartno: 10506542
	02	99058340	CYLINDER	1	vendorcode: KOMATSU \| visiblepartno: 99058340
	03	91391340	PISTON	1	vendorcode: KOMATSU \| visiblepartno: 91391340
	04	46104240	PISTON GUIDE RING	6	vendorcode: KOMATSU \| visiblepartno: 46104240
	05	94006540	PISTON GUID STRAP	2	vendorcode: KOMATSU \| visiblepartno: 94006540
	06	95151540	SCRAPER	1	vendorcode: KOMATSU \| visiblepartno: 95151540
	07	51041498	O-RING (COLD WEATHER DESIGN)	1	vendorcode: KOMATSU \| visiblepartno: 51041498
	08	95151440	SEAL RING	1	vendorcode: KOMATSU \| visiblepartno: 95151440
	09	46104040	SEAL RING	1	vendorcode: KOMATSU \| visiblepartno: 46104040
	10	51975298	O-RING	2	vendorcode: KOMATSU \| visiblepartno: 51975298
	\|$11	79961473	SEAL KIT CONSIST. OF FIG-NOS: 04-10	-1	vendorcode: KOMATSU \| visiblepartno: 79961473
	\|$12			-1
	\|$13			-1
	\|$14			-1
	\|$15			-1
	\|$16			-1
	\|$17			-1

Komatsu PC4000-11 S/N 08312 parts catalog PDF

HYDRAULIC TENSIONER (355-3118D) in PC4000-11 S/N 08312. Diagram image and parts list.
