LH FRAME RAIL WIRING 2/2 | AFE57-KF 830E-1AC S/N A41142 MODERN MACHINERY

AFE57-KF 830E-1AC S/N A41142 MODERN MACHINERY

2 2 3 4 5 31 5 4 19 5 4 3 15 5 4 3 23 5 4 3 5 14 3 4 3 4 5 20 6 13 5 4 3 7 4 5 8 15 4 5 16 17 18 4 5 19 3 13 3 11 5 4 21 3 4 5 29 30 32 5 4 3 4 5 16 3 16 32 5 4 3 28 27 26 25 4 5 24 22 14 2 3 4 5 6 13 5 4 29 24 12 30 32 31 9 6 4 5 3 33 34 3 4 5 6 12 5 4 10 3 6 13 5 4 3 17 3 1 3 3

#	Part Number	Partname	Quantity
1	AK7339	SENSOR, TEMPERATURE	1
2	TF6924	CLAMP, VINYL - 1 3/4"	6
3	MM0178	NUT - M10 X 1.50	31
4	MM0471	LOCKWASHER - M10	36
5	MM0461	FLAT WASHER - M10	36
6	EM1393	SPACER	6
7	58E-06-14900	HARNESS, WIRING - LH REAR FRAME RAIL	1
8	WB1302	CLAMP, CUSHIONED - 5/16"	1
9	WB3856	CLAMP, CUSHIONED - 1 1/8"	1
10	WB3098	CLAMP, CUSHIONED - 3/8"	3
11	SG0673	GROMMET, RUBBER	1
12	WB3857	CLAMP, CUSHIONED - 1 3/16"	7
13	TR9441	CLAMP, VINYL - 1 1/4" ID	6
14	58D-90-00730	CLAMP, CUSHIONED - 1 11/16"	3
15	WB3922	CLAMP, CUSHIONED - 11/16"	3
16	MM0611	CAPSCREW - M10 X 1.50 X 60	4
17	WB1304	CLAMP, CUSHIONED - 9/16"	1
18	08193-21012	CLIP	3
19	WB1303	CLAMP, CUSHIONED - 3/4"	2
20	WB3855	CLAMP, CUSHIONED - 13/16"	1
21	EL3892	SPACER	2
22	08192-12100	BODY, RECEPTACLE CONNECTOR	1
23	EM1398	SPACER	2
24	MM0606	CAPSCREW - M10 X 1.50 X 30	5
25	EL3706	MOUNT	1
26	TR4436	FLAT WASHER, HARDENED - 3/8"	1
27	TD0791	CAPSCREW - 3/8" - 16NC X 1 1/4"	1
28	TC1231	LOCKWASHER - 3/8"	1
29	WB3097	CLAMP, CUSHIONED - 1/2"	2
30	WB3094	CLAMP, CUSHIONED - 1 3/4"	3
31	WB1301	CLAMP, CUSHIONED - 1/4"	4
32	TY8375	SPACER	4
33	58E-06-14050	PLATE	1
34	58E-06-14180	HARNESS, WIRING - AUXILIARY CABINET - ENGINE	1
34	WB3092	CLAMP, CUSHIONED - 7/8"	1
