NSS
|
SPINDLE, HUB AND BRAKE ASSEMBLY |
1 |
|
|
|
|
? |
58B-32-00173
|
HUB ASSEMBLY, WHEEL |
1 |
|
|
|
|
? |
EK4352
|
STUD W/ HEAD |
57 |
|
|
|
|
? |
WB1199
|
PLUG, MAGNETIC |
1 |
|
|
|
|
? |
TH6916
|
VALVE, CHECK |
1 |
|
|
|
|
? |
PB7454
|
GAUGE, SIGHT |
1 |
|
|
|
|
? |
VC6561
|
CAPSCREW - 1/2" - 13NC X 1 1/2" |
12 |
|
|
|
|
? |
TR5445
|
LOCKWASHER - 1/2" |
12 |
|
|
|
|
? |
58B-32-00041
|
COVER |
1 |
|
|
|
|
? |
EK3776
|
O-RING (1) |
1 |
|
|
|
|
? |
VM8258
|
CAPSCREW - 1" - 8NC X 3 3/4" |
10 |
|
|
|
|
? |
TY2148
|
FLAT WASHER, HARDENED - 1" |
10 |
|
|
|
|
? |
58B-32-00290
|
RETAINER, BEARING |
1 |
|
|
|
|
? |
EH7190
|
O-RING (1) |
1 |
|
|
|
|
? |
EK2731
|
SHIM - .005" (1) |
4 |
|
|
|
|
? |
EK2732
|
SHIM - .007" (1) |
4 |
|
|
|
|
? |
EK2733
|
SHIM - .020" (1) |
6 |
|
|
|
|
? |
PB9996
|
CONE, ROLLER - TAPERED (1) |
1 |
|
|
|
|
? |
PC0002
|
CUP, ROLLER - TAPERED (1) |
1 |
|
|
|
|
? |
EH7195
|
O-RING (1) |
2 |
|
|
|
|
? |
VN9037
|
CAPSCREW - 3/8" - 16NC X 1 1/4" |
12 |
|
|
|
|
? |
WA4726
|
FLAT WASHER, HARDENED - 3/8" |
12 |
|
|
|
|
? |
58B-32-00060
|
SHIM - .020" (1) |
18 |
|
|
|
|
? |
58B-32-00050
|
SHIM - .010" (1) |
12 |
|
|
|
|
? |
58B-32-30000
|
CARRIER, SEAL |
1 |
|
|
|
|
? |
58F-32-40110
|
SEAL ASSEMBLY, FLOATING (1) |
1 |
|
|
|
|
? |
PC1431
|
SEAL, OIL (1) |
1 |
|
|
|
|
? |
58B-32-00461
|
FRONT BRAKE ASSEMBLY (SEE FIG 48645) |
1 |
|
48645 |
|
|
? |
58B-09-50080
|
FLAT WASHER, HARDENED - 1 1/4" |
44 |
|
|
|
|
? |
WB1231
|
CAPSCREW - 1 1/4" - 12NF X 8" |
32 |
|
|
|
|
? |
58F-32-00180
|
O-RING (1) |
1 |
|
|
|
|
? |
DF6928
|
CAPSCREW - 1/2" - 13NC X 1 3/4" |
24 |
|
|
|
|
? |
58B-32-00283
|
CARRIER, SEAL - HUB |
1 |
|
|
|
|
? |
58B-32-40000
|
SEAL ASSEMBLY (1) |
1 |
|
|
|
|
? |
58B-32-00262
|
CARRIER, SEAL - SPINDLE |
1 |
|
|
|
|
? |
EH7194
|
O-RING (1) |
1 |
|
|
|
|
? |
PC1131
|
CUP, ROLLER - TAPERED (1) |
1 |
|
|
|
|
? |
PC1130
|
CONE, ROLLER - TAPERED (1) |
1 |
|
|
|
|
? |
EK1288
|
SPACER |
1 |
|
|
|
|
? |
58B-32-00621
|
SPINDLE |
1 |
|
|
|
|
? |
WA3559
|
CHANNEL |
2 |
|
|
|
|
? |
562-22-32290
|
PIN |
2 |
|
|
|
|
? |
WA4174
|
FLAT WASHER - 1" |
54 |
|
|
|
|
? |
WA0908
|
CAPSCREW - 1" - 8NC X 3" |
54 |
|
|
|
|
? |
WB1134
|
NUT - 1 1/4" - 7NC (2) |
3 |
|
|
|
|
? |
58B-32-00370
|
BRACKET, SHIPPING (2) |
3 |
|
|
|
|
? |
C1643
|
CAPSCREW - 3/4" - 10NC X 1 3/4" (2) |
3 |
|
|
|
|
? |
WA0362
|
FLAT WASHER - 3/4" (2) |
3 |
|
|
|
|
? |
NSS
|
PLATE ASSEMBLY |
1 |
|
|
|
|
? |
TC1234
|
CAPSCREW - 3/8" - 16NC X 3/4" |
2 |
|
|
|
|
? |
WA0720
|
FLAT WASHER, HARDENED - 3/8" |
2 |
|
|
|
|
? |
58F-32-50050
|
PLUG, OIL SAMPLING |
1 |
|
|
|
|
? |
58F-32-50040
|
COVER, DUST |
1 |
|
|
|
|
? |
58C-09-00010
|
CAPSCREW - 1/4" - 20NC X 1/2" |
6 |
|
|
|
|
? |
H8402
|
PLUG - 3/8" |
1 |
|
|
|
|
? |
|
|
-1 |
|
|
|
|
? |
58B-SM-AK030
|
NOTE: (1) INCLUDED IN 58B-SM-AK030 SPINDLE MAINTENANCE KIT. |
-1 |
|
|
|
|
? |
|
(2) FOR SHIPPING AND STORAGE USE ONLY. |
-1 |
|
|
|
|
? |
|
(QUANTITIES SHOWN ARE FOR ONE SIDE ONLY.) |
