FRONT SUSPENSION ASSEMBLY | AFE75-BC 980E-5 S/N A50221 KCH

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE75-BC 980E-5 S/N A50221 KCH

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	58B-50-40341	FRONT SUSPENSION ASSEMBLY	1
?	58B-50-00760	HOUSING	1
?	WA0360	FLAT WASHER, HARDENED - 1/2"	1
?	VN9032	CAPSCREW - 1/2" - 13NC X 1"	1
?	58F-50-00370	PLUG	1
?	58B-50-00710	RETAINER, UPPER BEARING	1
?	WA0363	FLAT WASHER, HARDENED - 7/8"	60
?	VN9105	CAPSCREW - 7/8" - 9NC X 3"	36
?	58B-60-01240	BEARING, UPPER	1
?	58B-50-00920	LOCKPIN (1)	1
?	58B-50-00040	NUT, WHEEL	1
?	58B-50-00890	STOP, PISTON	1
?	SC3100	KEY, SQUARE	1
?	58B-50-40380	O-RING (1)	4
?	58B-50-40390	RING, BACKUP (1)	4
?	58B-50-00790	CAP, SUSPENSION	1
?	TY8879	PLUG, VENT (1)	1
?	VD5076	GASKET, FLAT (1)/(2)	1
?	PB2194	CHARGING VALVE ASSEMBLY (1)/(2)	1
?	EM9996	COVER, PROTECTOR	1
?	C1602	CAPSCREW - 3/8" - 16NC X 1"	2
?	DF3042	FLAT WASHER - 3/8"	2
?	TZ8637	PLUG, SENSOR	1
?	58B-60-01230	BEARING, LOWER	1
?	58B-50-50000	RETAINER, LOWER BEARING	1
?	58B-60-01220	SEAL, BUFFER (1)	1
?	58B-50-00180	SEAL, WIPER (1)	1
?	VN9161	CAPSCREW - 7/8" - 9NC X 4"	24
?	VN2710	CAPSCREW - 1" - 8NC X 5 1/2"	28
?	WA0364	FLAT WASHER, HARDENED - 1"	28
?	58B-50-40370	SEAL, MAIN (1)	1
?	58B-50-00801	PISTON ASSEMBLY	1
?	H2981	BALL, STEEL (1)	4
?	58B-50-00170	PLATE, WIPER RETAINER	4
?	WA0443	O-RING (1)	1
?	WA1443	RING, BACKUP (1)	1
?	EM3159	PLUG, PISTON	1
?	EM1585	RING, RETAINER	3
?	EM1600	PLATE, RETAINER	1
?	VM0314	PLUG (1)	1
?	AK4063	SUSPENSION OIL MIXTURE - 5 GAL	-2
?	AK4064	SUSPENSION OIL MIXTURE - 55 GAL	-2
?			-1
?	58B-FS-AK020	NOTE: (1) INCLUDED IN 58B-FS-AK020 SEAL KIT.	-1
?	RK1887	(2) INCLUDED IN RK1887 CHARGING VALVE KIT.	-1
?		(QUANTITIES SHOWN ARE FOR ONE SIDE ONLY.)	-1
