D375A-6 S/N 62001-UP (Mining Specification)

9 8 17 16 15 14 13 12 11 7 6 5 4 3 1 10 20 19 18 2

#	Part Number	Partname	Quantity	Options	Reference
\|$0	195-22-80001	Power Unit, With VHMS	1	SN: 60962-UP
\|$1	195-22-80051	Power Unit, With VHMS	1	SN: 60322-60961 \| SCC: A2
\|$2	195-22-80050	Power Unit, With VHMS	1	SN: 60001-60321 \| SCC: A2
\|$3	195-15-81007	Transmission Assembly	1	SN: 60962-UP
\|$4	195-15-81006	Transmission Assembly	1	SN: (101703)-60961
\|$5	195-15-81005	Transmission Assembly	1	SN: (101237)-(101702) \| SCC: A2
\|$6	195-15-81004	Transmission Assembly	1	SN: (101214)-(101236) \| SCC: A2
\|$7	195-15-81003	Transmission Assembly	1	SN: (101193)-(101213) \| SCC: A2
\|$8	195-15-81002	Transmission Assembly	1	SN: (100740)-(101192) \| SCC: A2
\|$9	195-15-81001	Transmission Assembly	1	SN: (100654)-(100739) \| SCC: A2
\|$10	195-15-81000	Transmission Assembly	1	SN: 60001-(100653) \| SCC: A2
\|$11	195-15-03030	Housing Assembly	1	SN: 60434-UP
1		Housing	1	SN: 60434-UP \| SCC: C1
2	145-14-11320	Plug	2	SN: 60434-UP
3	175-15-59240	Seal Ring, (Kit : K02)	1	SN: 60001-UP
4	155-15-12820	Seal Ring, (Kit : K02)	1	SN: 60001-UP
5	195-15-42771	Piston	1	SN: 60001-UP
6	175-15-42781	Spring	12	SN: 60001-UP
7	195-15-71171	Housing	1	SN: 60001-UP
8	195-15-41251	Bolt	17	SN: 60001-UP
9	195-15-11290	Washer	17	SN: 60001-UP
10	175-15-59292	Seal Ring	1	SN: 60001-UP
11	195-15-41290	Pin	12	SN: 60001-UP
12	195-15-82270	Hub	1	SN: 60001-UP
13	195-15-49250	Seal Ring	1	SN: 60001-UP
14	195-15-49230	Seal Ring	1	SN: 60001-UP
15	06330-06924	Bearing	1	SN: 60001-UP
16	06330-06924	Bearing	1	SN: 60001-UP
17	195-15-42290	Gear	1	SN: 60001-UP
18	195-15-42780	Plate(Power Train,2nd and 3rd Housing)	-1	SN: UP	F2300-001011
19	195-15-42690	Gear,Ring(Power Train,1st Housing)	-1	SN: UP	F2300-001010
20	195-15-42324	Carrier(Power Train,Carrier)	-1	SN: UP	F2300-001013
\|$32		[A2]-The part specified in the line above can be used instead of this part.	-1	SN: UP
\|$33		[C1]-This part cannot be supplied as an individual part. It is supplied as an assembly.	-1	SN: UP

Komatsu D375A-6 S/N 62001-UP (Mining Specification) parts catalog PDF

POWER TRAIN, FORWARD AND REVERSE HOUSING(#60001-) (F2300-001012) in D375A-6 S/N 62001-UP (Mining Specification). Diagram image and parts list.
