D375A-6 S/N 62001-UP (Mining Specification)

5 1 2 3 4 6 7 2

#	Part Number	Partname	Quantity	Options
\|$0	195-22-80001	Power Unit, With VHMS	1	SN: 60962-UP
\|$1	195-22-80051	Power Unit, With VHMS	1	SN: 60322-60961 \| SCC: A2
\|$2	195-22-80050	Power Unit, With VHMS	1	SN: 60001-60321 \| SCC: A2
\|$3	195-15-81007	Transmission Assembly	1	SN: 60962-UP
\|$4	195-15-81006	Transmission Assembly	1	SN: (101703)-60961
\|$5	195-15-81005	Transmission Assembly	1	SN: (101237)-(101702) \| SCC: A2
\|$6	195-15-81004	Transmission Assembly	1	SN: (101214)-(101236) \| SCC: A2
\|$7	195-15-81003	Transmission Assembly	1	SN: (101193)-(101213) \| SCC: A2
\|$8	195-15-81002	Transmission Assembly	1	SN: (100740)-(101192) \| SCC: A2
\|$9	195-15-81001	Transmission Assembly	1	SN: (100654)-(100739) \| SCC: A2
\|$10	195-15-81000	Transmission Assembly	1	SN: 60001-(100653) \| SCC: A2
\|$11	195-15-95100	Valve Assembly, Transmission Control	1	SN: (101237)-UP
\|$12	195-15-85101	Valve Assembly, Transmission Control	1	SN: (101104)-(101236)
\|$13	195-15-85100	Valve Assembly, Transmission Control	1	SN: 60001-(101103) \| SCC: A2
1	195-15-00317	Valve Assembly	1	SN: (101237)-UP
\|$15	195-15-00316	Valve Assembly	1	SN: (100931)-(101236) \| SCC: A1
\|$16	195-15-00315	Valve Assembly	1	SN: (100931)-(101103) \| SCC: B1
\|$17	195-15-00314	Valve Assembly, Upper	1	SN: 60001-(100930) \| SCC: A2
2	01252-90510	Bolt, Hexagon Socket Head	20	SN: (100931)-UP
\|$19	01252-60510	Bolt, Hexagon Socket Head	20	SN: 60001-(100930)
3	195-15-77341	Bracket	3	SN: 60001-UP
4	195-15-77351	Bracket	2	SN: 60001-UP
5	195-15-00325	Valve Assembly	1	SN: (100931)-UP
\|$23	195-15-00324	Valve Assembly, Lower	1	SN: 60001-(100930) \| SCC: A2
6	195-15-76320	Sleeve	5	SN: 60001-UP
7	195-15-76330	Filter	5	SN: 60001-UP
\|$26		[A1]-This part and the part specified in the line immediately above are interchangeable.	-1	SN: UP
\|$27		[A2]-The part specified in the line above can be used instead of this part.	-1	SN: UP
\|$28		[B1]-This shows discontinued part. The part specified in the above line is supplied instead.	-1	SN: UP

Komatsu D375A-6 S/N 62001-UP (Mining Specification) parts catalog PDF

POWER TRAIN, TRANSMISSION CONTROL VALVE (ECMV)(#60001-) (F2300-001019) in D375A-6 S/N 62001-UP (Mining Specification). Diagram image and parts list.
