PC490LC-11 S/N 87001-UP

Komatsu parts book diagram for PC490LC-11 S/N 87001-UP: CONTROL VALVE, 8-SPOOL (8/24)(#85001-)

? ? ? ? ? ? ? ? ? ? ? ?

	#	Part Number	Partname	Quantity	Options	Reference
	?	723-48-28404	Valve Assembly, Control, With Arm Hydraulic Drift Prevention Valve	1	SN: 85910-UP
	?	723-48-28403	Valve Assembly, Control, With Arm Hydraulic Drift Prevention Valve	1	SN: 85482-85909 \| SCC: A2
	?	723-48-28402	Valve Assembly, Control, With Arm Hydraulic Drift Prevention Valve	1	SN: 85382-85481 \| SCC: A2
	?	723-48-28401	Valve Assembly, Control, With Arm Hydraulic Drift Prevention Valve	1	SN: 85111-85381 \| SCC: A2
	?	723-48-28400	Valve Assembly, Control, With Arm Hydraulic Drift Prevention Valve	1	SN: 85001-85110 \| SCC: A2
	?	723-40-56800	Valve Assembly	2	SN: 85001-UP
	?	07000-B2014	O-ring	1	SN: 85001-UP
	?	723-40-56350	Ring, Back-up	1	SN: 85001-UP
	?	07000-B2016	O-ring	1	SN: 85001-UP
	?	723-60-22230	Ring, Back-up	1	SN: 85001-UP
	?	07002-62434	O-ring	1	SN: 85001-UP
	?		[A2]-The part specified in the line above can be used instead of this part.	-1	SN: UP

Komatsu PC490LC-11 S/N 87001-UP parts catalog PDF

CONTROL VALVE, 8-SPOOL (8/24)(#85001-) (H0120-001008) in PC490LC-11 S/N 87001-UP. Diagram image and parts list.
