723-48-28403
|
Valve Assembly, Control, With Arm Hydraulic Drift Prevention Valve |
1 |
SN: 85482-UP
|
|
|
|
? |
723-48-28402
|
Valve Assembly, Control, With Arm Hydraulic Drift Prevention Valve |
1 |
SN: 85382-85481 | SCC: A2
|
|
|
|
? |
723-48-28401
|
Valve Assembly, Control, With Arm Hydraulic Drift Prevention Valve |
1 |
SN: 85111-85381 | SCC: A2
|
|
|
|
? |
723-48-28400
|
Valve Assembly, Control, With Arm Hydraulic Drift Prevention Valve |
1 |
SN: 85001-85110 | SCC: A2
|
|
|
|
? |
|
Body Subassembly |
1 |
SN: 85001-UP | SCC: C1
|
|
|
|
? |
723-46-45700
|
Valve Assembly |
2 |
SN: 85001-UP
|
|
|
|
? |
708-2L-23960
|
O-ring |
1 |
SN: 85001-UP
|
|
|
|
? |
723-46-41950
|
Ring, Back-up |
2 |
SN: 85001-UP
|
|
|
|
? |
07002-63634
|
O-ring |
1 |
SN: 85001-UP
|
|
|
|
? |
01252-60845
|
Bolt, Hexagon Socket Head |
4 |
SN: 85001-UP
|
|
|
|
? |
01643-50823
|
Washer |
4 |
SN: 85001-UP
|
|
|
|
? |
|
[A2]-The part specified in the line above can be used instead of this part. |
-1 |
SN: UP
|
|
|
|
? |
|
[C1]-This part cannot be supplied as an individual part. It is supplied as an assembly. |
-1 |
SN: UP
|
|
