TORQUE CONVERTER AND TRANSMISSION, INPUT SHAFT(#30001-) | HD785-7 S/N 37001-UP

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity	Options
\|$0	561-13-70011	TORQFLOW Assembly	1	SN: 33227-UP
\|$1	561-13-70010	TORQFLOW Assembly	1	SN: 30001-33226 \| SCC: B1
\|$2	561-13-71001	Torque Converter Assembly	1	SN: 33227-UP
\|$3	561-13-71000	Torque Converter Assembly	1	SN: 30001-33226 \| SCC: B1
1	561-13-71351	Shaft	1	SN: 30001-UP
2	711-23-11240	Bearing, (Kit : K05)	1	SN: 30001-UP
3	19M-13-21370	Seal Ring, (Kit : K01, K02, K03, K04, K05)	2	SN: 30001-UP
4	01010-61655	Bolt	18	SN: 30001-UP
5	01643-31645	Washer	18	SN: 30001-UP
6	561-13-79372	Retainer	1	SN: 33227-UP
\|$10	561-13-79371	Retainer	1	SN: 30001-33226 \| SCC: B1
7	07012-50125	Seal, Oil, (Kit : K01, K02, K03, K04, K05)	1	SN: 30001-UP
8	426-15-59180	Seal, Dust, (Kit : K03, K04, K05)	1	SN: (109653)-UP
\|$13	772-19-14280	Seal, Dust, (Kit : K01, K02)	1	SN: 30001-(109652) \| SCC: A2
9	07000-75170	O-ring, (Kit : K01, K02, K03, K04, K05)	1	SN: 30001-UP
10	01010-81030	Bolt	2	SN: 30001-UP
11	01643-31032	Washer	2	SN: 30001-UP
12	561-13-79862	Coupling Assembly	1	SN: 33227-UP
\|$18	561-13-79861	Coupling	1	SN: 30001-33226 \| SCC: B1
13	04064-09530	Ring, Snap	1	SN: 30001-UP
14	561-13-75380	Bushing, (Kit : K05)	1	SN: 30001-UP
\|$21		[A2]-The part specified in the line above can be used instead of this part.	-1	SN: UP
\|$22		[B1]-This shows discontinued part. The part specified in the above line is supplied instead.	-1	SN: UP
