|$0 |
561-13-70012
|
TORQFLOW Assembly |
1 |
SN: (113580)-UP
|
|
|
|
|$1 |
561-13-70011
|
TORQFLOW Assembly |
1 |
SN: 33227-(113579) | SCC: A2
|
|
|
|
|$2 |
561-13-70010
|
TORQFLOW Assembly |
1 |
SN: 30001-33226 | SCC: B1
|
|
|
|
|$3 |
561-13-71001
|
Torque Converter Assembly |
1 |
SN: 33227-UP
|
|
|
|
|$4 |
561-13-71000
|
Torque Converter Assembly |
1 |
SN: 30001-33226 | SCC: B1
|
|
|
|
|$5 |
561-13-89011
|
Housing Assembly |
1 |
SN: (108938)-UP
|
|
|
|
|$6 |
561-13-79010
|
Housing Assembly |
1 |
SN: (105402)-(108937) | SCC: A2
|
|
|
|
1 |
|
Housing |
1 |
SN: (108938)-UP | SCC: C1
|
|
|
|
|$8 |
|
Cover |
1 |
SN: (105402)-(108937) | SCC: C1
|
|
|
|
2 |
720-2M-11550
|
Plug |
1 |
SN: (105402)-UP
|
|
|
|
3 |
07002-62034
|
O-ring, (Kit : K02, K04, K05) |
1 |
SN: (105402)-UP
|
|
|
|
4 |
07000-73035
|
O-ring, (Kit : K02, K03, K04, K01, K05) |
3 |
SN: 30001-UP
|
|
|
|
5 |
07000-73048
|
O-ring, (Kit : K02, K03, K04, K01, K05) |
2 |
SN: 30001-UP
|
|
|
|
6 |
708-8E-16150
|
Plug |
1 |
SN: 30001-UP
|
|
|
|
7 |
07002-61023
|
O-ring, (Kit : K02, K03, K04, K01, K05) |
1 |
SN: 30001-UP
|
|
|
|
8 |
561-13-53150
|
O-ring, (Kit : K02, K03, K04, K01, K05) |
1 |
SN: 30001-UP
|
|
|
|
9 |
01010-61640
|
Bolt |
16 |
SN: 30001-UP
|
|
|
|
10 |
01643-31645
|
Washer |
16 |
SN: 30001-UP
|
|
|
|
11 |
01010-61655
|
Bolt |
16 |
SN: 30001-UP
|
|
|
|
12 |
01643-31645
|
Washer |
16 |
SN: 30001-UP
|
|
|
|
13 |
7861-93-3320
|
Sensor, Temperature, Torque Converter Outlet Oil, (Kit : K05) |
1 |
SN: 30001-UP
|
|
|
|
14 |
561-13-79630
|
Plug |
1 |
SN: 30001-UP
|
|
|
|
|$22 |
|
[A2]-The part specified in the line above can be used instead of this part. |
-1 |
SN: UP
|
|
|
|
|$23 |
|
[B1]-This shows discontinued part. The part specified in the above line is supplied instead. |
-1 |
SN: UP
|
|
|
|
|$24 |
|
[C1]-This part cannot be supplied as an individual part. It is supplied as an assembly. |
-1 |
SN: UP
|
|
