CONTROL VALVE, 8-SPOOL (18/23)(#75001-76990) | PC450LC-8R S/N 79001-UP

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

PC450LC-8R S/N 79001-UP

4 8 7 5 3 2 1 6 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 23

#	Part Number	Partname	Quantity	Options
\|$0	723-48-27508	Valve Assembly, Control	1	SN: 76991-77998
\|$1	723-48-27507	Valve Assembly, Control	1	SN: 76313-76990 \| SCC: A2
\|$2	723-40-85300	Valve Assembly	1	SN: 76469-76990
\|$3	723-40-82401	Valve Assembly	1	SN: 75001-76468 \| SCC: A2
1		Body	1	SN: 75975-76990 \| SCC: C1
\|$5		Body	1	SN: 75001-75974 \| SCC: C1
2		Valve	1	SN: 75001-76990 \| SCC: C1
3		Seal	1	SN: 75001-76990 \| SCC: C1
4	723-40-82210	Plug	1	SN: 75001-76990
5	723-40-82220	Filter	1	SN: 75001-@
6	723-40-82140	Spring	1	SN: 75001-76990
7	723-40-82150	Plug	1	SN: 75001-76990
8	07002-63334	O-ring	1	SN: 75001-76990
9	723-40-84420	Valve, Check	1	SN: 75001-@
10	723-40-84430	Spring	1	SN: 75001-@
11		Plug	1	SN: 75975-@ \| SCC: C1
\|$16		Plug	1	SN: 75001-75974 \| SCC: C1
12	07000-B3024	O-ring	1	SN: 75001-@
13		Plug	1	SN: 75001-@ \| SCC: C1
14	07002-61823	O-ring	1	SN: 75001-@
15	07000-B2011	O-ring	1	SN: 75001-@
16	07001-02011	Ring, Back-up	1	SN: 75001-@
17	07000-B1010	O-ring	1	SN: 75001-@
18	07001-01010	Ring, Back-up	1	SN: 75001-@
19	723-11-18190	Plug	1	SN: 75001-@
20	07002-61023	O-ring	1	SN: 75001-@
21		Piston	1	SN: 76469-@ \| SCC: C1
\|$27		Piston	1	SN: 75001-76468 \| SCC: C1
22	723-40-82290	Spring	1	SN: 75001-@
23		Plug, Stocking	2	SN: 75001-76990 \| SCC: C1
24	01252-61075	Bolt, Hexagon Socket Head	4	SN: 75001-@
25	723-46-17570	Block	1	SN: 75001-@
26	01252-61045	Bolt, Hexagon Socket Head	4	SN: 75001-@
\|$33		[A2]-The part specified in the line above can be used instead of this part.	-1	SN: UP
\|$34		[C1]-This part cannot be supplied as an individual part. It is supplied as an assembly.	-1	SN: UP
