PC450LC-8R S/N 79001-UP

Komatsu parts book diagram for PC450LC-8R S/N 79001-UP: CONTROL VALVE, VALVE BRACKET AND SENSOR(#75001-)

6 5 4 2 3 1 6 7 7

	#	Part Number	Partname	Quantity	Options	Reference
	1	208-62-71111	Bracket	1	SN: 75001-UP
	2	01010-81640	Bolt	5	SN: 75001-UP
	3	01643-31645	Washer	5	SN: 75001-UP
	4	01010-81645	Bolt	3	SN: 75001-UP
	5	01643-31645	Washer	3	SN: 75001-UP
	6	7861-93-1891	Sensor, Pressure, Front Pump,Rear Pump	2	SN: 77331-UP
	\|$6	7861-93-1890	Sensor, Pressure, Front Pump,Rear Pump	2	SN: 76820-77330 \| SCC: A2
	\|$7	7861-93-1812	Sensor, Pressure, Front Pump,Rear Pump	2	SN: 75101-76819 \| SCC: A1
	\|$8	7861-93-1811	Sensor, Pressure, Front Pump,Rear Pump	2	SN: 75001-75100 \| SCC: A2
	7	07002-61823	O-ring	1	SN: 75101-UP
	\|$10	07002-11823	O-ring	1	SN: 75001-75100
	\|$11		[A1]-This part and the part specified in the line immediately above are interchangeable.	-1	SN: UP
	\|$12		[A2]-The part specified in the line above can be used instead of this part.	-1	SN: UP

Komatsu PC450LC-8R S/N 79001-UP parts catalog PDF

CONTROL VALVE, VALVE BRACKET AND SENSOR(#75001-) (H0120-004026) in PC450LC-8R S/N 79001-UP. Diagram image and parts list.
