Komatsu parts book diagram for PC2000-11E0 S/N 31001-UP: FAN PUMP, PISTON PUMP (2/11)(#30001-)

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

	#	Part Number	Partname	Quantity	Options	Reference
	?	708-2L-00280	Pump Assembly	1	SN: 30001-UP
	?	708-2L-01280	Pump Subassembly	1	SN: 30001-UP \| SCC: C2
	?	708-2L-06121	Cap Assembly	1	SN: 30001-UP \| SCC: C2
	?		Cap	1	SN: 30001-UP \| SCC: C1
	?		Plug, Stocking	15	SN: 30001-UP \| SCC: C1
	?	708-2L-32260	Bearing	2	SN: 30001-UP \| SCC: C2
	?	708-2L-22271	Ring, Snap	1	SN: 30001-UP \| SCC: C2
	?	07000-A5165	O-ring	2	SN: 30001-UP \| SCC: C2
	?	04020-01228	Pin, Dowel	2	SN: 30001-UP \| SCC: C2
	?	07000-B2012	O-ring	7	SN: 30001-UP \| SCC: C2
	?	07000-B2014	O-ring	4	SN: 30001-UP \| SCC: C2
	?	708-2L-25480	Filter	4	SN: 30001-UP \| SCC: C2
	?	01010-61450	Bolt	12	SN: 30001-UP \| SCC: C2
	?	01643-31445	Washer, Flat	12	SN: 30001-UP \| SCC: C2
	?	708-8E-16150	Plug	3	SN: 30001-UP
	?	07002-61023	O-ring	3	SN: 30001-UP
	?		[C1]-This part cannot be supplied as an individual part. It is supplied as an assembly.	-1	SN: UP
	?		[C2]-This part is supplied for authorized Komatsu distributors only. It cannot be supplied as an individual part. It is supplied as an assembly.	-1	SN: UP

Komatsu PC2000-11E0 S/N 31001-UP parts catalog PDF

FAN PUMP, PISTON PUMP (2/11)(#30001-) (H0230-001002) in PC2000-11E0 S/N 31001-UP. Diagram image and parts list.
