A2359-001001 PISTON AND CONNECTING ROD | PC220LCi-12 S/N A15001

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity
\|$0	6757-31-2100	PISTON KIT	4
\|$1	6757-31-2010	RING ASSEMBLY, PISTON	1
1	NSS	RING, OIL	1
2	NSS	RING, TOP	1
3	NSS	RING, SECOND	1
4	6757-31-2110	PISTON	1
5	6732-31-2420	RING	2
6	6754-31-2410	PIN	4
\|$8	6755-31-3110	CONNECTING ROD ASSEMBLY	4
7	6732-31-3320	SCREW	2
8	6755-31-3120	BUSHING	1
9	NSS	ROD, CONNECTING	1
10	6754-32-3410	BEARING, UPPER, STANDARD	4
\|$13	6754-32-3420	BEARING, UPPER, UNDERSIZE, 0.25MM	4
\|$14	6754-32-3430	BEARING, UPPER, UNDERSIZE, 0.50MM	4
\|$15	6754-32-3440	BEARING, UPPER, UNDERSIZE, 0.75MM	4
\|$16	6754-32-3450	BEARING, UPPER, UNDERSIZE, 1.00MM	4
11	6732-31-3420	BEARING, LOWER, STANDARD	4
\|$18	6738-39-3400	BEARING, LOWER, UNDERSIZE, 0.25MM	4
\|$19	6738-38-3400	BEARING, LOWER, UNDERSIZE, 0.50MM	4
\|$20	6738-37-3400	BEARING, LOWER, UNDERSIZE, 0.75MM	4
\|$21	6738-36-3400	BEARING, LOWER, UNDERSIZE, 1.00MM	4
\|$$23			-1
\|$$24		F1 - THIS INDICATES A PART SUPPLIED AS SEMI-FINISHED. IT REQUIRES ADDITIONAL WORK BEFORE INSTALLA TION.	-1
