WHEEL MOTOR ROTOR ASSEMBLY 1/2 | AFE78-FD 930E-5 S/N A40629 - A40631 KSA

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity
\|$1	58F-30-00200	WHEEL MOTOR ASSEMBLY	1
1	58F-22-01410	STATOR ASSEMBLY	1
2	GE0112	RING, BUS (TC)	1
3	GE0113	RING, BUS (TB)	1
4	GE0114	RING, BUS (TA)	1
5	GE0115	RING, BUS (N)	1
6	VE4526	CAPSCREW - 3/8" - 16NC X 1"	18
7	VE3027	FLAT WASHER - 3/8"	27
8	VE4700	NUT - 3/8" - 16NC (INNER)	9
9	58F-22-01420	ROTOR ASSEMBLY (INNER)	1
10	GE0437	SHAFT (INNER)	1
11	XA4575	NUT	1
12	GE0123	LOCKWASHER	1
13	58F-22-01430	WEIGHT, BALANCING (INNER)	-2
14	GE0119	WHEEL, SENSOR	1
15	GE0124	FRAME, HEAD	1
16	GE0125	CAP, BEARING	1
17	GE0126	COLLAR (OUTER)	1
18	GE0127	BEARING (1)/(2)/(3)	1
19	GE0128	COLLAR (INNER)	1
20	VE4518	CAPSCREW - 1/2" - 13NC X 1 1/2"	8
21	VE5185	FLAT WASHER - 1/2" (INNER)	8
22	VE4830	CAPSCREW - 5/8" - 11NC X 2"	18
23	XA4136	FLAT WASHER, HARDENED - 5/8"	18
24	GE0136	BLOCK	1
25	GE0137	CLAMP	1
26	GE1367	CONNECTION, STRAP	3
27	XA4256	SENSOR, SPEED	1
28	VE4640	CAPSCREW - 3/8" - 16NC X 1 1/2"	4
29	VE4515	FLAT WASHER - 3/8"	14
30	VE4747	NUT	5
31	VE4701	CAPSCREW - 3/8" - 16NC X 3"	2
32	VE4783	PUTTY	-2
33	58F-22-01450	TAPE, POLYESTER	-2
34	58F-22-01460	TAPE, FIBERGLASS	-2
35	VE7272	SEALANT	-2
36	VE4641	CAPSCREW - 3/8" - 16NC X 1 1/4"	3
37	GE0628	CAPSCREW - 5/16" - 18NC X 2 1/4"	2
38	58E-00-01570	FLAT WASHER - 5/16"	2
39	GE0142	CEMENT	-2
40	58F-22-01470	TAPE, GLASS	1
41	VE4687	LOCKWASHER - 3/8"	5
\|$43			-1
KT\|44	58F-WM-AK040	NOTE: (1) INCLUDED IN 58F-WM-AK040 BEARING KIT.	-1
KT\|45	58F-WM-AK050	(2) INCLUDED IN 58F-WM-AK050 BEARING/SEAL KIT.	-1
KT\|46	58F-WM-AK150	(3) INCLUDED IN 58F-WM-AK150 WHEEL MOTOR	-1
		OVERHAUL KIT. BALANCE OF PARTS ON	-1
		PREVIOUS AND FOLLOWING PAGES.	-1
