BACKHOE 15 CBM WITH WEAR AND TEAR PARTS (WP3) | PC3000-6 S/N 46235

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity
01		Backhoe assy. fig.-no.: 25-40 (without lip and teeth)	1
03	947 690 40	Lip with tooth adapters	1
04	941 259 40	Center adapter	3
05	941 261 40	Corner adapter, left	1
06	941 260 40	Corner adapter, right	1
07	940 626 40	Pin Assembly	5
08	941 254 40	Tooth (RC)	5
08	941 255 40	Tooth (SC)	5
09	932 501 40	Shroud l.h.	2
10	932 502 40	Shroud r.h.	2
11	940 026 40	J-bolt assy.	4
12	906 104 40	Retainer	4
13	948 603 40	Shroud	2
14	948 612 40	Wear plate outside	2
15	948 613 40	Wear plate inside	2
16	933 543 40	Wear strip	1
17	933 544 40	Wear strip	2
18	925 591 40	Wear plate	2
19	904 436 40	Wear plate	4
20	933 558 40	Wear plate	2
21	933 559 40	Wear plate	2
22	933 561 40	Wear plate	2
23	933 562 40	Wear plate	2
24	933 563 40	Wear plate inside	10
25	942 608 40	Pin with plate	1
26	942 610 40	Pin with plate	1
27	904 495 40	Flanged bush	2
28	904 496 40	Flanged bush	2
29	913 032 40	Ring	2
30	926 850 40	Cap	1
31	926 855 40	Cap	1
32	925 982 40	Stop	8
33	904 498 40	Square	4
34	904 499 40	Catch	2
35	319 442 99	Bolt	2
36	342 085 99	Cotter pin	2
37	332 361 99	Nut	2
38	332 338 99	Nut	2
39	925 981 40	Safety sleeve	2
40		Backhoe, weldment	1
45	941 256 40	Wear Cap	3
46	941 257 40	Lower Wing Shroud	3
